| Weight & dimensions |
| Width |
329.3 mm |
| Depth |
280.8 mm |
| Height |
188.2 mm |
| Weight |
6.76 kg |
| Package weight |
8.41 kg |
| Power |
| Power supply location |
Built-in |
| Power supply unit (PSU) capacity |
250 W |
| Number of power supply units |
1 |
| Power consumption (typical) |
54.067 W |
| Power consumption (sleep) |
25.668 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Output current |
3.5 A |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100,1000,2500 Mbit/s |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Jumbo frames support |
Yes |
| iSCSI support |
Yes |
| Wake-on-LAN ready |
Yes |
| Link aggregation |
Yes |
| Load balancing system |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| WLAN adapter supported |
Yes |
| License |
| License quantity |
1 license(s) |
| License type |
Upgrade |
| Software type |
Electronic License Delivery (ELD) |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
2 |
| USB port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
3 |
| PCI Express x4 (Gen 3.x) slots |
2 |
| Memory |
| Internal memory |
8 GB |
| Internal memory type |
DDR4 |
| Maximum RAM supported |
64 GB |
| Memory slots |
2 |
| Memory form factor |
SO-DIMM |
| ECC |
Yes |
| Flash memory |
5120 MB |
| Processor |
| Processor family |
Ryzen Embedded |
| Processor manufacturer |
AMD |
| Processor model |
V1500B |
| Processor frequency |
2.2 GHz |
| Processor generation |
AMD Ryzen Embedded V1000 Series |
| Processor cores |
4 |
| Number of processors supported |
1 |
| Storage |
| Storage drives installed |
Yes |
| Total installed storage capacity |
144 TB |
| Number of storage drives supported |
8 |
| Installed storage drive type |
HDD |
| Supported storage drive types |
HDD & SSD |
| Storage drive interface |
Serial ATA III |
| RAID support |
Yes |
| Supported storage drive interfaces |
M.2, Serial ATA II, Serial ATA III |
| Storage drive size |
3.5" |
| Storage drive sizes supported |
2.5,3.5,M.2 |
| Number of M.2 (M & B) slots |
2 |
| RAID levels |
0, 1, 5+S, 5, 6, 6+HS, 10+HS, 10, 50, 60, JBOD |
| Online RAID migration |
Yes |
| Online RAID expansion |
Yes |
| RAID rebuild |
Yes |
| Hot-swap drive bays |
Yes |
| Supported file systems |
FAT32, HFS+, NTFS, ext3, ext4 |
| Bad block scan |
Yes |
| Disk roaming |
Yes |
| Packaging content |
| Cables included |
AC, LAN (RJ-45) |
| Number of screws |
48 |
| Features |
| Compatibility |
3PAR 7400 |
| Performance |
| Type |
NAS |
| Device class |
Small & Medium Business |
| Backup function |
Yes |
| Backup features |
Cloud, USB drive, iSCSI LUN |
| Buzzer |
Yes |
| Number of users |
4096 user(s) |
| Noise level |
23 dB |
| Third-party support |
Yes |
| Snapshot |
Yes |
| Management protocols |
SNMP |
| Web-based management |
Yes |
| Share folder access right management |
Yes |
| Security algorithms |
256-bit AES, FIPS 140-2, HTTPS, SNMPv2, SNMPv3, SSH |
| Access Control List (ACL) |
Yes |
| Reset button |
Yes |
| On/off switch |
Yes |
| Built-in BitTorrent client |
Yes |
| Built-in FTP server |
Yes |
| Browser supported |
Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox |
| System log |
No |
| Hot spare |
Yes |
| S.M.A.R.T. support |
Yes |
| Share folder |
512 |
| Backup button |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| USB copy function |
Yes |
| Design |
| Chassis type |
Tower |
| Cooling type |
Active |
| Product colour |
Anthracite |
| Number of fans |
3 fan(s) |
| Fan diameter |
12 cm |
| Fan diameter 2 |
6 cm |
| LED indicators |
HDD, LAN, Power, SSD, Status |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Logistics data |
| Harmonized System (HS) code |
84714100 |
| Software |
| Operating system installed |
QNAP Turbo System |
| Operating system version |
4.52 |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x |
| Linux operating systems supported |
CentOS 7.0, Solaris 10 U4, Solaris 10 U5, Ubuntu 14.04, openSUSE 12.1, openSUSE 12.2 |
| Mac operating systems supported |
Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina |
| Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
