Weight & dimensions |
Width |
482 mm |
Depth |
724 mm |
Height |
88 mm |
Power |
Power supply location |
Built-in |
Power supply unit (PSU) capacity |
500 W |
Number of power supply units |
1 |
Redundant power supply (RPS) support |
Y |
Power consumption (typical) |
156.23 W |
Power consumption (HDD standby) |
72.37 W |
AC input voltage |
100 - 240 V |
AC input frequency |
50/60 Hz |
Operational conditions |
Operating temperature (T-T) |
0 - 35 °C |
Operating relative humidity (H-H) |
5 - 95% |
Storage temperature (T-T) |
-20 - 60 °C |
Storage relative humidity (H-H) |
5 - 95% |
Operating altitude |
0 - 5000 m |
Networking |
Ethernet LAN |
Y |
Ethernet LAN data rates |
10,100,1000,1200,2500,5000,10000 Mbit/s |
Ethernet LAN data rate supported (max) |
10000 Mbit/s |
Wi-Fi |
N |
iSCSI support |
Y |
Wake-on-LAN ready |
Y |
Supported network protocols |
SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN |
Link aggregation |
Y |
Ports & interfaces |
Ethernet LAN (RJ-45) ports |
6 |
USB port |
Y |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
PCI Express x8 (Gen 3.x) slots |
2 |
Memory |
Internal memory |
16 GB |
Internal memory type |
DDR4 |
Maximum RAM supported |
128 GB |
Memory slots |
4 |
Memory form factor |
RDIMM |
Processor |
Processor family |
Intel® Xeon® D |
Processor manufacturer |
Intel |
Processor model |
D-1567 |
Processor frequency |
2.1 GHz |
Processor boost frequency |
2.7 GHz |
Processor cores |
12 |
Processor threads |
24 |
Processor cache |
18 MB |
CPU configuration (max) |
1 |
ECC supported by processor |
Y |
PCI Express configurations |
1x16, 1x4, 1x8 |
PCI Express slots version |
2.0, 3.0 |
Processor cache type |
L3 |
Processor code |
SR2M3 |
Processor codename |
Broadwell |
Processor lithography |
14 nm |
Processor operating modes |
64-bit |
Processor package size |
37.5 x 37.5 mm |
Processor series |
Intel Xeon D-1500 |
Processor socket |
BGA 1667 |
Scalability |
1S |
Stepping |
Y0 |
Thermal Design Power (TDP) |
65 W |
Maximum internal memory supported by processor |
128 GB |
Conflict-Free processor |
Y |
Other features |
Digital Living Network Alliance (DLNA) certified |
Y |
Processor ARK ID |
93356 |
Storage |
Storage drives installed |
Y |
Total installed storage capacity |
120 TB |
Number of storage drives installed |
12 |
Number of storage drives supported |
12 |
Installed storage drive type |
HDD |
Supported storage drive types |
HDD & SSD |
Storage drive capacity |
10000 GB |
RAID support |
Y |
Supported storage drive interfaces |
Serial ATA, Serial Attached SCSI (SAS) |
Storage drive size |
2.5/3.5" |
Storage drive sizes supported |
2.5,3.5" |
Maximum supported storage capacity |
192 TB |
RAID levels |
0, 1, 5, 6, 10, F1, JBOD |
Online RAID migration |
Y |
Online RAID expansion |
Y |
Hot-swap drive bays |
Y |
Supported file systems |
BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4 |
Packaging content |
Cables included |
AC |
Quick installation guide |
Y |
Features |
Number of years |
5 year(s) |
Service type |
Next Business Day |
Compatibility |
DL980 |
Performance |
Type |
NAS |
Device class |
Small & Medium Business |
Backup function |
Y |
Backup features |
Cloud, iSCSI LUN |
Buzzer |
Y |
Multilingual support |
Y |
Number of users |
16000 user(s) |
Noise level |
49.8 dB |
Snapshot |
Y |
Web-based management |
Y |
Share folder access right management |
Y |
Security algorithms |
HTTPS, SSH, SSL/TLS |
Access Control List (ACL) |
Y |
On/off switch |
Y |
Built-in iTunes server |
Y |
Built-in FTP server |
Y |
Browser supported |
Chrome, Firefox, Edge, Internet Explorer, Safari |
System log |
Y |
Hot spare |
Y |
Design |
Chassis type |
Rack (2U) |
Cooling type |
Active |
Product colour |
Black |
Number of fans |
4 fan(s) |
Fan diameter |
8 cm |
LED indicators |
Y |
Technical details |
Sustainability certificates |
RoHS |
Processor special features |
Embedded options available |
Y |
Enhanced Intel SpeedStep Technology |
Y |
Execute Disable Bit |
Y |
Idle States |
Y |
Intel 64 |
Y |
Intel Enhanced Halt State |
Y |
Intel Secure Key Technology version |
1.00 |
Intel Trusted Execution Technology |
Y |
Intel TSX-NI |
Y |
Intel TSX-NI version |
1.00 |
Intel Virtualization Technology (VT-x) |
Y |
Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
Intel VT-x with Extended Page Tables (EPT) |
Y |
Intel® AES New Instructions (Intel® AES-NI) |
Y |
Intel® Hyper Threading Technology (Intel® HT Technology) |
Y |
Intel® OS Guard |
Y |
Intel® Secure Key |
Y |
Intel® Turbo Boost Technology |
2.0 |
Maximum number of PCI Express lanes |
32 |
Thermal Monitoring Technologies |
Y |
UART |
Y |
Memory channels supported by processor |
Dual |
Memory types supported by processor |
DDR3-SDRAM, DDR4-SDRAM |
Software |
Operating system installed |
DiskStation Manager |
Windows operating systems supported |
Windows 10, Windows 7 |
Mac operating systems supported |
Y |
Server operating systems supported |
Windows Server 2016 |
