| Ports & interfaces |
| Ethernet LAN |
Yes |
| USB port |
Yes |
| USB connector |
USB Type-A |
| USB 2.0 ports quantity |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Direct printing |
Yes |
| Wi-Fi Direct |
Yes |
| RJ-45 ports quantity |
1 |
| Mobile printing technologies |
HP ePrint |
| Printing |
| Print technology |
Inkjet |
| Colour |
Yes |
| Maximum resolution |
2400 x 1200 DPI |
| Number of print cartridges |
6 |
| Page description languages |
PostScript 3, PDF 1.7, HP-GL/2, TIFF, JPEG, HP-RTL, CALS G4 |
| Printing colours |
Cyan, Photo black, Matte black, Magenta, Yellow |
| Print resolution colour |
2400 x 1200 DPI |
| Print speed (normal quality) |
66.9 m²/hr |
| Print head |
3 |
| Power |
| Power consumption (typical) |
100 W |
| Power consumption (off) |
0.1 W |
| Power consumption (sleep) |
6.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Operational conditions |
| Operating temperature (T-T) |
5 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-25 - 55 °C |
| System requirements |
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Paper handling |
| Maximum print size |
A1 (594 x 841 mm) |
| Paper tray media types |
Coated paper, Bond paper, Photo paper, Banner |
| Cut sheets |
Yes |
| ISO A-series sizes (A0...A9) |
A1, A2, A3, A4 |
| Media thickness |
0.8 mm |
| Maximum roll width |
61 cm |
| Maximum roll diameter |
13.5 cm |
| Media width (sheets) |
610 mm |
| Roll widths supported |
279 - 610mm |
| Custom media sizes |
210 x 279 to 610 x 1676 mm |
| Weight & dimensions |
| Width |
1293 mm |
| Depth |
695 mm |
| Height |
998 mm |
| Weight |
66 kg |
| Scanning |
| Scanning |
No |
| Copying |
| Copying |
No |
| Other features |
| Electromagnetic compatibility |
Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS) |
| Safety |
EU (LVD and EN 60950-1 compliant); Russia, Belarus, Kazakhstan (EAC) |
| UNSPSC-code |
43212104 |
| Performance |
| Product colour |
Grey |
| Built-in display |
Yes |
| Display |
LED |
| Internal memory |
4096 MB |
| Internal storage capacity |
500 GB |
| Storage media |
HDD |
| Sound power level (standby) |
33 dB |
| Sound pressure level (printing) |
42 dB |
| Country of origin |
China, Thailand |
| Certification |
Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS) |
| HP segment |
Business |
| Technical details |
| Box contents |
HP DesignJet Z6 PostScript Printer, printheads, introductory ink cartridges, printer stand and media bin, spindle, quick reference guide, setup poster, power cord |
| Brand-specific features |
| HP ePrint |
Yes |
| HP Web Jetadmin |
Yes |
| HP Dynamic security |
Yes |
| HP Care Pack |
Yes |
| HP GTIN (EAN/UPC) |
192018667501 |
| Logistics data |
| Harmonized System (HS) code |
84433210 |
| Packaging data |
| Package width |
1440 mm |
| Package depth |
766 mm |
| Package height |
718 mm |
| Package weight |
97 kg |
| Cartridge(s) included |
Yes |
| Drivers included |
Yes |
| Quick start guide |
Yes |
| Bundled software |
HP Click printing software, HP PrintOS, HP Web Jetadmin, HP DesignJet Utility including HP Color Center, HP Partner Link, HP JetAdvantage Security Manager (optional), HP SmartStream (optional) |
| Sustainability |
| Sustainability certificates |
ENERGY STAR |
| Sustainable technologies and materials |
30% post-consumer recycled plastic; Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; Highest WIR Print Permanence Ratings in the Industry; Compatible with FSC®-certified HP large format printing materials and HP Recycled |
| Sustainability compliance |
Yes |
| Carbon footprint |
| Total carbon footprint (kg of CO2e) |
820 |
| Carbon emissions, manufacturing (kg of CO2e) |
755 |
| Carbon emissions, logistics (kg of CO2e) |
52 |
| Carbon emissions, end-of-life (kg of CO2e) |
1 |
| Total carbon emissions, w/o use phase (kg of CO2e) |
7 |
