| Printing |
| Print speed (black, normal quality, A4/US Letter) |
43 ppm |
| Maximum resolution |
1200 x 1200 DPI |
| Standard printer languages |
PCL 5,PCL 6,PDF 1.4 |
| Time to first page (black, normal) |
10 s |
| Print speed (black, best quality, A4) |
43 ppm |
| Print speed (black, best quality, letter) |
Up to 45 ppm |
| Printing |
N |
| Duplex printing |
Y |
| Input capacity |
| Standard input capacity |
1100 sheets |
| Maximum input capacity |
2100 sheets |
| Maximum input capacity for envelopes |
Up to 75 |
| Paper handling |
100-sheet multi-purpose tray, two 500-sheet input trays, optional two additional 500-sheet input trays,50-sheet Automatic Document Feeder (ADF), automatic two-sided printing, 500-sheet stacker, 30-sheet stapler |
| Output capacity |
| Maximum output capacity |
700 sheets |
| Standard output capacity for envelopes |
100 sheets |
| Weight & dimensions |
| Weight |
99.4 kg |
| Package weight |
171 kg |
| Scanning |
| Optical scanning resolution |
600 x 600 DPI |
| Maximum scan area |
227 x 302 mm |
| Scan type |
Flatbed |
| Input colour depth |
30 bit |
| Gray scale levels |
256 |
| Scan input modes |
Front-panel scan, Copy, Fax, e-mail, ADF |
| Scanner features |
Colour scanning of up to A4 size documents, 50 page ADF |
| Scan speed (black, normal quality) |
Up to 45 ppm |
| Minimum scan size |
No minimum |
| Send to email (Digital Sender) |
Y |
| Scanner type |
Flatbed scanner |
| Greyscale levels |
256 |
| Scanning |
Colour scanning |
| Duplex scanning |
Y |
| Copying |
| Maximum copy resolution |
600 x 600 DPI |
| Maximum number of copies |
1000 copies |
| Copy resolution (black graphics) |
Up to 600 x 600 dpi |
| Copy speed (best quality, black, A4) |
43 cpm |
| Left metric copy margin |
4.2 |
| Right metric copy margin |
4.2 |
| Top metric copy margin |
4.2 |
| Copier settings |
Sides, staple collate, image adjustment, reduce/enlarge, paper selection, content orientation, output bin, pages per sheet, booklet format, optimize text/picture, original size, job build, edge to edge |
| Bottom copy margin |
4.2 |
| Maximum copy speed (black, A4) |
43 cpm |
| Copy speed (black, best, letter) |
Up to 45 cpm |
| Time to first copy (letter) |
< 10 sec |
| Copying |
N |
| Fax |
| Modem speed |
33.6 Kbit/s |
| Auto-redialing |
Y |
| Fax broadcasting |
100 locations |
| Fax delayed sending |
N |
| Fax speed dialing (max numbers) |
100 |
| Auto reduction |
Y |
| Fax forwarding |
Y |
| Distinctive ring |
N |
| Telecom compliance (fax capability) |
Telecom: TBR-21:1998; EG 201 121:1998, FCC Part 68, Industry Canada CS03, NOM-151-SCTI-1999 (Mexico), PTC-200 (New Zealand), AS/ACIF S002:2001 (Australia), IDA PSTN1 (Singapore), TPS002-01 (Malaysia), IG 0005-11 (Taiwan), HKTA 2011 (Hong Kong), YD514, YD/ |
| Fax resolution black photo grayscale |
200 x 200 dpi |
| Fax resolution standard mode (black & white) |
200 x 200 dpi |
| Fax resolution superfine mode (black & white) |
Up to 300 x 300 dpi |
| Faxing |
Colour faxing |
| Power |
| Power consumption (PowerSave) |
16 W |
| Operational conditions |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage temperature (T-T) |
0 - 35 °C |
| Operating temperature (T-T) |
50 - 91 °F |
| Storage relative humidity (H-H) |
10 - 80% |
| Recommended operating temperature range (T-T) |
10 - 32.5 °C |
| Operating altitude (imperial) |
10000 ft |
| Paper handling |
| Media weight (tray 1) |
60 to 200 g/m² |
| Auto Document Feeder (ADF) media weight |
60 to 120 |
| Envelope feeder |
Yes, 75 (with the purchase of an optional envelope feeder) |
| Recommended media weight |
Tray 1: 60 - 200, Tray 2: 60 - 120, Tray 3: 60 - 120 |
| Media handling |
Sheetfed |
| Maximum paper trays |
5 |
| Paper handling optional/input |
two 500-sheet input trays |
| Paper handling optional/output |
Optional 3-bin mailbox with one 500-sheet bin and two 100-sheet bins |
| Paper handling standard/input |
100-sheet multipurpose tray, two 500-sheet input trays (2, 3), 50-sheet ADF, automatic two-sided printing accessory |
| Paper handling standard/output |
500-sheet stacker, 30-sheet stapler |
| Media type and capacity (tray 2) |
Sheets: 500, tranparencies: 100 |
| Media type and capacity (tray 3) |
Sheets: 500, tranparencies: 100 |
| Paper handling |
100-sheet multi-purpose tray, two 500-sheet input trays, optional two additional 500-sheet input trays,50-sheet Automatic Document Feeder (ADF), automatic two-sided printing, 500-sheet stacker, 30-sheet stapler |
| Maximum print size |
211.9 x 351.6 mm |
| Networking |
| Supported network protocols (IPv4) |
IPv6: DHCPv6, HTTP, HTTPS, Port 9100, LPD, IIP, Secure IIP, MLDv6, ICMPv6; IPv4: FTP, IPP, Secure IPP, Auto-IP, Apple Bonjour Compatible, Telnet, SLP, IGVPv2, BOOTP/DHCP, WINS, SNMPv1/v2c/v3, TFTP, HTTP, HTTPS, Port9100, LPD; other: IPX/SPX, DLC, LLC, App |
| Display |
| Display diagonal |
43.2 cm (17") |
| System requirements |
| Minimum system requirements |
133 MHz processor or higher, 64 MB RAM, 40 MB available hard disk space, USB or network port |
| Storage |
| Internal memory |
256 MB |
| Internal storage capacity |
40 GB |
| Packaging data |
| Package weight |
171 kg |
| Certificates |
| Energy Star certified |
Y |
| Blue Angel certified |
Y |
| Electromagnetic compatibility |
CISPR 22: 1993/EN 55022: 1994 Class B, EN 61000-3-2: 2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries t |
| Operating system/software |
| Copier smart software features |
Up to A4 capable copying on the glass, up to legal size through the automatic document feeder, 50 page ADF, duplexing (optional on base unit), reduce/enlarge, contrast adjustments, mixed original support |
| Printer smart software features |
Up to legal-size capable printing, full LaserJet printing functionality, HP ProRes 1200 at full engine speed, duplexing available, Instant-on Technology, HP Smart printing technology |
| Downloadable software |
Printing system, PCL 6 driver only, PCL 5 driver only, PostScript driver only, WJA applet, UPD PCL 5, UPD PostScript, HP Easy Printer Care Software, PC fax driver |
| SureSupply software driver |
Y |
| Software |
| Copier smart software features |
Up to A4 capable copying on the glass, up to legal size through the automatic document feeder, 50 page ADF, duplexing (optional on base unit), reduce/enlarge, contrast adjustments, mixed original support |
| Printer smart software features |
Up to legal-size capable printing, full LaserJet printing functionality, HP ProRes 1200 at full engine speed, duplexing available, Instant-on Technology, HP Smart printing technology |
| Downloadable software |
Printing system, PCL 6 driver only, PCL 5 driver only, PostScript driver only, WJA applet, UPD PCL 5, UPD PostScript, HP Easy Printer Care Software, PC fax driver |
| SureSupply software driver |
Y |
| Other features |
| Standard input trays |
3 |
| Networking features |
Via HP Jetdirect Embedded Network Print Server, HP Jetdirect internal print servers, HP Jetdirect external print servers, HP wireless print servers, HP connectivity cards |
| Dimensions (WxDxH) |
1016 x 744 x 1110 mm |
| Network ready |
Y |
| Power requirements |
Input voltage 220 to 240 VAC (+/- 10%), 50/60 Hz (+/-2 Hz), recommended circuit capacity 8 amps |
| Modem type |
33.6 Kbps |
| Media types supported |
Paper (plain, preprinted, letterhead, prepunched, bond, recycled, colour, rough), transparencies, labels, envelopes, card stock |
| Standard output capacity for transparancies |
500 sheets |
| Scan file formats |
JPG,PDF,TIFF |
| Safety |
Argentina (TUV S Mark-Rs.92/98/Ds.1009/98), Australia (AS/NZ 3260), Canada (cUL-CAN/CSA C22.2 No.60950-00), China (GB4943), EU (CE Mark-Low Voltage Directive 73/23/EEC), Germany (TÜV- EN60950-IEC 60825-1), Russia (GOST- R50377), USA (UL-UL 60950; FDA-21 C |
| Compatible operating systems |
Microsoft Windows 2000, XP Home, XP Professional, XP Professional x64, Server 2003; Windows Vista supported soon (visit /go/windowsvista for more information); Mac OS X v 10.2 or higher |
| Functions |
Print, copy, send-to email/network folder, fax, advanced paper handling (stapler/stacker) |
| Size |
102.1 cm (40.2") |
| Handset |
Y |
| Maximum scan area (ADF) |
216 x 356 mm |
| Minimum scan area (ADF) |
148 x 210 mm |
| All-in-one functions |
Fax, Scan |
| Colour all-in-one functions |
Fax, Scan, N |
| Package dimensions (WxDxH) |
1200 x 1000 x 1440 mm |
| Media size (tray 1) |
A4, A5, B5 (JIS), executive (JIS), 16K, D postcard (JIS), letter, legal, executive, statement, 8.5 x 13 in, envelopes (DL, C5, B5, No. 10, Commercial), custom 76 x 127 to 216 x 356 mm |
| I/O ports |
1 USB (compatible with USB 2.0 specifications), 1 network port (HP Fast Ethernet embedded print server), 1 Foreign Interface Harness (FIH) port, 1 fax connection, 1 EIO slot, 1 Jetlink for paper handling accessories |
| Acoustic power emissions |
6.9 B(A) (printing at 45 ppm) |
| Acoustic pressure emissions |
54 dB |
| Custom media sizes |
Tray 1, optional 3-bin mailbox or stacker part of stapler/stacker: 76 x 127 to 216 x 356 mm; Tray 2 and optional Tray 3, 4, 5: 148 x 210 to 216 x 356 mm; custom sizes not supported on optional automatic two-sided printing unit, envelope feeder, stapler |
| Duplex print options |
Automatic (standard) |
| Media weights by paper path |
Tray 1, optional stacker: 60 to 200 g/m2; Tray 2, optional 500-sheet input tray, optional automatic two-sided printing unit, optional stapler: 60 to 120 g/m2; optional envelope feeder: 75 to 105 g/m2 |
| Pallet dimensions (W x D x H) |
1200 x 1000 x 1440 mm |
| Pallet weight |
171 kg |
| Print quality (black, draft quality) |
600 DPI |
| Quantity per pallet |
1 pc(s) |
| Standard media sizes |
A4, A5, B5 (JIS), executive (JIS), 16K, envelopes (DL ISO, B5 ISO, C5 ISO) |
| Typefaces |
28 built in |
| Minimum system requirements for Macintosh |
Mac OS 10.2 and higher, 128 MB RAM, 25 MB available hard disk space, network or USB port |
| Print quality (black, best quality) |
1200 x 1200 DPI |
| Print quality (black, normal quality) |
1200 DPI |
| Maximum dimensions (W x D x H) |
925 x 566 x 549 mm |
| Print margin bottom (A4) |
4.2 mm |
| Print margin left (A4) |
4.2 mm |
| Print margin right (A4) |
4.2 mm |
| Print margin top (A4) |
4.2 mm |
| Driver updates |
The latest software and drivers are available for the HP LaserJet M4345 MFP from the HP Web site at http:///support/ljm4345mfp |
| Duplex supported media size |
A4, A5, B5 (JIS), executive (JIS), 16K |
| Image scaling/enlargement range |
25 - 400% |
| Memory upgrade |
0.512 GB |
| Memory technology |
Memory Enhancement technology (MEt) |
| Control panel |
VGA graphical touch screen, contrast control dial, numeric keypad, sleep button, reset button, stop button, start button, attention light, data light, ready light |
| Upgrade type |
Add additional paper handling capability with a 75-sheet envelope feeder, 3-bin mailbox, DSS software |
| Service & support |
HP Web sites, HP Customer Support Centre, HP Care Packs, HP service agreement |
| Auto document feeder: supported media types and capacity |
Sheets: 50 |
| Media weight (tray 2) |
60 to 120 g/m² |
| Media weight (tray 3) |
60 to 120 g/m² |
| Media size (tray 2) |
A4, A5, B5 (JIS), executive (JIS), 16K, letter, legal, executive, 8.5 x 13 in, custom 148 x 210 to 216 x 356 mm |
| Media size (tray 3) |
A4, A5, B5 (JIS), executive (JIS), 16K, letter, legal, executive, 8.5 x 13 in, custom 148 x 210 to 216 x 356 mm |
| Maximum scan area |
22.6 cm (8.9") |
| Package dimensions (W x D x H) |
1200.2 x 1000.3 x 1440.2 mm (47.2 x 39.4 x 56.7") |
| Weight |
152.53 lb |
| Standard input capacity for envelopes |
10 sheets |
| Acoustic power emissions (active, print, copy or scan) |
72 dB |
| Acoustic power emissions (ready) |
Inaudible |
| Acoustic pressure emissions bystander (active, print, copy or scan) |
56 dB(A)
54 dB(A) |
| Acoustic pressure emissions bystander (ready) |
Inaudible |
| Auto fax reduction supported |
Y |
| Copier scaling (Auto Document Feeder) |
25 to 400% |
| Duplex binding |
Y |
| Fax memory (letter) |
Dependent on the amount of available disk space pages |
| Fax phone TAM interface supported |
N |
| Fax resolution (photo) |
200 x 200 dpi |
| Fax telephone mode supported |
Y |
| Feed speed (black & white, letter) |
Up to 45 ppm |
| Feed speed (colour, letter) |
Up to 30 ppm |
| First page out (black&white, A4, ready) |
10 s |
| First page out (black&white, duplex, letter, ready) |
As fast as 10 sec |
| First page out (black&white, letter, ready) |
10 s |
| Junk barrier supported |
Y |
| Maximum input capacity (tray 1) |
100 sheets |
| Maximum input capacity (tray 2) |
Sheets: 500, tranparencies: 100 |
| Maximum input capacity (tray 3) |
Sheets: 500, tranparencies: 100 |
| Maximum printable area |
211.9 x 351.6 mm |
| Maximum scan area (Auto Document Feeder) |
8.5 x 14 |
| Media sizes supported (imperial) |
Letter, legal, executive, statement, 8.5 x 13 in, envelopes (No. 10, commercial) |
| Memory per slot (maximum) |
512 |
| Memory per slot (standard) |
256 MB (internal fixed), 0 MB (installed) |
| Minimum scan area (Auto Document Feeder) |
147.3 x 210.8 mm (5.8 x 8.3") |
| Minimum scan area |
0 x 0 mm (0 x 0") |
| Package weight |
376.2 lb |
| Paper sizes supported (Auto Document Feeder) |
Letter, legal, A4, A5, custom |
| PhotoSmart compression |
JPEG |
| Print speed (grayscale, normal quality, A4 transparency) |
Up to 21 ppm |
| Remote retrieval capability |
Y |
| SureSupply connection type |
Direct and Network |
| SureSupply supported |
Y |
| Wireless option type |
Optional, enabled with purchase of a hardware accessory |
| Product dimensions (with optional paper finisher, imperial) |
36.4 x 22.3 x 21.6 in (base bundle with added stapler/stacker or multi-bin mailbox) |
| Product dimensions (with optional paper finisher, metric) |
925 x 566 x 549 mm (base bundle with added stapler/stacker or multi-bin mailbox) |
| Standard media sizes (duplex, imperial) |
Letter, legal, executive, 8.5 x 13 in |
| Standard media sizes (duplex, metric) |
A4, A5, B5 (JIS), executive (JIS), 16K |
| UNSPSC-code |
43212110 |
| Digital sender features |
Send to e-mail, send to network folder, LDAP and SMTP authentification, LDAP addressing |
| Security management description |
SNMPv3, SSL/TLS (HTTPS), 802.1x authentication, Web Jetadmin |
| Pallet dimensions (W x D x H) (imperial) |
1201.4 x 1000.8 x 1440.2 mm (47.3 x 39.4 x 56.7") |
| Pallet weight (imperial) |
170.6 kg (376.2 lbs) |
| Weight (imperial) |
152.53 lb |
| Maximum scan area (ADF) (imperial) |
215.9 x 355.6 mm (8.5 x 14") |
| Package weight (imperial) |
170.6 kg (376.2 lbs) |
| Standard output capacity for transparencies |
500 sheets |
| Printer management |
HP Web Jetadmin, HP Easy Printer Care Software (neither is shipped in box) |
| Downloadable software |
Printing system, PCL 6 driver only, PCL 5 driver only, PostScript driver only, WJA applet, UPD PCL 5, UPD PostScript, HP Easy Printer Care Software, PC fax driver |
| Size (imperial) |
102.1 cm (40.2") |
| Electromagnetic compatibility |
CISPR 22: 1993/EN 55022: 1994 Class B, EN 61000-3-2: 2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries t |
| Copier smart software features |
Up to A4 capable copying on the glass, up to legal size through the automatic document feeder, 50 page ADF, duplexing (optional on base unit), reduce/enlarge, contrast adjustments, mixed original support |
| Printer smart software features |
Up to legal-size capable printing, full LaserJet printing functionality, HP ProRes 1200 at full engine speed, duplexing available, Instant-on Technology, HP Smart printing technology |
| Maximum scan area (imperial) |
22.6 cm (8.9") |
| Performance |
| Printing |
N |
| Copying |
N |
| Scanning |
Colour scanning |
| Faxing |
Colour faxing |
| Maximum duty cycle |
200000 pages per month |
| Digital sender |
N |
| Duplex functions |
print,scan |
| Number of print cartridges |
1 |
| All-In-One-multitasking |
Y |
| Printer management |
HP Web Jetadmin, HP Easy Printer Care Software (neither is shipped in box) |
| Built-in processor |
Y |
| Processor clock speed |
480 MHz |
| Source data-sheet |
|
| Processor frequency |
480 MHz |
| Market positioning |
Business |
| Internal memory |
256 MB |
| Internal storage capacity |
40 GB |
| Processor model |
MIPS |
| Processor family |
MIPS |
| Minimum system requirements |
133 MHz processor or higher, 64 MB RAM, 40 MB available hard disk space, USB or network port |
| Design |
| Display diagonal |
43.2 cm (17") |
| Blue Angel certified |
Y |
| Electromagnetic compatibility |
CISPR 22: 1993/EN 55022: 1994 Class B, EN 61000-3-2: 2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries t |
| Market positioning |
Business |
| Features |
| Printing |
N |
| Copying |
N |
| Scanning |
Colour scanning |
| Faxing |
Colour faxing |
| Maximum duty cycle |
200000 pages per month |
| Energy Star certified |
Y |
| Market positioning |
Business |
| Digital sender |
N |
| Duplex functions |
Print,Scan |
| Number of print cartridges |
1 |
| All-In-One-multitasking |
Y |
| Printer management |
HP Web Jetadmin, HP Easy Printer Care Software (neither is shipped in box) |
| Blue Angel certified |
Y |
| Electromagnetic compatibility |
CISPR 22: 1993/EN 55022: 1994 Class B, EN 61000-3-2: 2000, EN 61000-3-3: 1995, EN 55024: 1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries t |
| Page description languages |
PCL 5,PCL 6,PDF 1.4 |
| Processor |
| Built-in processor |
MIPS in HP custom ASIC |
| Processor frequency |
480 MHz |
| Logistics data |
| Pallet weight |
171 kg |
| Quantity per pallet |
1 pc(s) |
| Pallet gross weight |
171 kg |
| Products per pallet |
1 pc(s) |
| Input & output capacity |
| Standard input capacity |
1100 sheets |
| Maximum input capacity |
2100 sheets |
| Maximum output capacity |
700 sheets |
| Maximum input capacity for envelopes |
Up to 75 |
| Standard output capacity for envelopes |
100 sheets |
| Total input capacity |
1100 sheets |
| Technical details |
| Sustainability certificates |
Blue Angel, ENERGY STAR |
| Sustainability |
| Sustainability certificates |
Blue Angel, ENERGY STAR |
