| Printing |
| Print speed (black, normal quality, A4/US Letter) |
50 ppm |
| Warm-up time |
60 s |
| Time to first page (black, normal) |
8.5 s |
| Colour |
N |
| Duplex printing |
Y |
| Maximum resolution |
1200 x 1200 DPI |
| Weight & dimensions |
| Weight |
28.3 kg |
| Dimensions (WxDxH) |
419 x 538 x 394 mm |
| Package weight |
29.6 kg |
| Package dimensions (WxDxH) |
790 x 600 x 540 mm |
| Maximum dimensions (W x D x H) |
419 x 952 x 584 mm |
| Pallet dimensions (W x D x H) |
1200 x 800 x 2310 mm |
| Pallet weight |
260 kg |
| Width |
419.1 mm |
| Depth |
925.2 mm |
| Height |
58.4 mm |
| Input capacity |
| Standard input capacity |
600 sheets |
| Output capacity |
| Standard output capacity |
600 sheets |
| Maximum output capacity |
600 sheets |
| Print technology |
| Colour |
N |
| Maximum resolution |
1200 x 1200 DPI |
| Duplex printing |
Y |
| Number of print cartridges |
1 |
| Recommended duty cycle |
3000 |
| Maximum duty cycle |
225000 pages per month |
| Ports & interfaces |
| PictBridge |
N |
| System requirements |
| Minimum system requirements for Macintosh |
Mac OS X v10.2 or higher; PowerPC G3, G4, G5, or Intel Core processor; 160 MB free hard disk space; CD-ROM drive, USB port or IEEE 1284-B compliant parallel port (via HP1284B Parallel Card J7972G) |
| Memory |
| Internal memory |
128 MB |
| Hard drive capacity |
Optional |
| Card reader integrated |
N |
| HDD capacity |
Optional |
| Power |
| Power consumption (PowerSave) |
12 W |
| Paper handling |
| ISO A-series sizes (A0...A9) |
A4,A5 |
| Standard tray media types |
Bond paper,Envelopes,Labels,Plain paper,Recycled paper,Transparencies |
| Non-ISO print media sizes |
Executive |
| JIS B-series sizes (B0...B9) |
B5 |
| Duplex media weight |
60 - 120 g/m² |
| Media types supported |
Paper (bond, colour, letterhead, plain, preprinted, prepunched, recycled, rough, light), envelopes, labels, cardstock, transparencies |
| Media size (tray 1) |
A4, A5, B5 (JIS), letter, legal, executive, statement, 16K, Dpostcard (JIS), Executive (JIS), envelope (Com10, Monarch #7-3/4, DL ISO, C5 ISO, B5 ISO), 76 x 127 mm to 216 x 356 mm |
| Media weight (tray 1) |
60 to 200 g/m² |
| Maximum ISO A-series paper size |
A4 |
| Paper tray media types |
Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies |
| Operational conditions |
| Operating temperature (T-T) |
50 - 90 °F |
| Storage temperature (T-T) |
0 - 35 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage relative humidity (H-H) |
10 - 95% |
| Non-operating altitude |
9100 |
| Networking |
| Network ready |
Y |
| Supported network protocols (IPv4) |
IPv4/IPv6: SNMPv1/v2c/v3, HTTP, HTTPS, FTP, Port 9100, LPD, IPP, Secure-IPP, WS Discovery, IPsec/Firewall; IPv6: DHCPv6, MLDv1, ICMPv6; IPv4: Auto-IP, SLP, TFTP, Telnet, IGMPv2, BOOTP/DHCP, WINS, IP Direct Mode, WS Print; IPX/SPX, AppleTalk, NetWare NDS, |
| Ethernet LAN |
Y |
| Wi-Fi |
N |
| Certificates |
| Energy Star certified |
N |
| Blue Angel certified |
N |
| Certification |
IEC 60950-1\nEN 60950-1+A11 (EU)\nIEC 60825-1+A1+A2\nUL/cUL\nGS\nEN 60825-1+A1+A2 GB4943-2001\n |
| Other features |
| Minimum system requirements |
Microsoft Windows 2000: 133 MHz processor, 64 MB RAM, CD-ROM drive; Microsoft Windows XP Home and Professional: 233 MHz processor, 64 MB RAM, CD-ROM drive; Microsoft Windows Server 2003: 550 MHz processor, 128 MB RAM (standard edition), 220 MB of free har |
| Printer management |
HP Web Jetadmin, HP LaserJet Utility, HP Embedded Web Server, HP Easy Printer Care |
| Power requirements |
Input voltage 100 to 127 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz); 220 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz) |
| Electromagnetic compatibility |
CISPR 22: 2005/EN 55022: 2006 Class B, EN 61000-3-2: 2000+A2, EN 61000-3-3: 1995+A1, EN 55024: 1998+A1+A2, FCC Title 47 CFR, Part 15 Class B (USA), ICES-003, Issue 4, (Canada), GB9254-1998, EMC Directive 2004/108/EC with CE Marking (Europe), other EMC app |
| Standard input trays |
2 |
| Networking features |
HP Jetdirect 10/100/1000Base-TX Ethernet embedded print server
Gigabit Ethernet, 802.11b wireless, 802.11g wireless |
| Standard output capacity for transparancies |
600 sheets |
| Safety |
IEC 60950-1 (International), EN 60950-1+A11 (EU), IEC 60825-1+A1+A2, UL/cUL Listed (US/Canada), GS License (Europe), EN 60825-1+A1+A2 (Class 1 Laser/LED Device) GB4943-2001, Low Voltage Directive 2006/95/EC with CE Marking (Europe); other safety approvals |
| Compatible operating systems |
Microsoft Windows 2000, XP Home, XP Professional; Server 2003; Certified for Windows Vista; Mac OS X v10.2, v10.3 or higher |
| Product dimensions when open (LxWxD) |
41.9 cm (16.5") |
| Size |
41.9 cm (16.5") |
| Recommended operating temperature range (T-T) |
10 - 32 °C |
| I/O ports |
1 x USB 2.0
1 x EIO
1+2 Host USB 2.0 |
| Input capacity for envelopes (primary tray) |
10 sheets |
| Custom media sizes |
Multipurpose tray: 76 x 127 to 216 x 356 mm; Tray 2 and optional 500-sheet tray: 148 x 210 to 148 x 356 mm; custom media cassette: 102 x 148 to 170 x 282 mm |
| Standard media sizes |
A4, A5, B5 (JIS), 16K, Dpostcard (JIS), Executive (JIS), envelope (DL ISO, C5 ISO, B5 ISO) |
| Print margin bottom (A4) |
6 mm |
| Print margin left (A4) |
5 mm |
| Print margin right (A4) |
5 mm |
| Print margin top (A4) |
6 mm |
| Typefaces |
80 HP font set (plus Greek, Hebrew, Cyrillic, Arabic) |
| Media weights by paper path |
Multipurpose tray 1: 60 to 200 g/m², standard cassette (Tray 2): 60 to 120 g/m², optional custom media cassette (Tray 2): 60 to 120 g/m², optional envelope feeder: 75 to 105 g/m², optional 500-sheet trays: 60 to 120 g/m², optional 1500-sheet high-capacity |
| Standard output capacity for envelopes |
10 sheets |
| Minimum system requirements for Macintosh |
Mac OS X v10.2 or higher; PowerPC G3, G4, G5, or Intel Core processor; 160 MB free hard disk space; CD-ROM drive, USB port or IEEE 1284-B compliant parallel port (via HP1284B Parallel Card J7972G) |
| Envelope feeder |
Yes, 75 |
| Acoustic power emissions |
7.2 B(A) (active/printing), 4.1 B(A) (ready) |
| Duplex print options |
Automatic (standard) |
| Duty cycle letter size (maximum) |
225000 pages per month |
| Print speed (black, best quality, A4) |
50 ppm |
| Quantity per pallet |
16 pc(s) |
| Print quality (black, best quality) |
1200 x 1200 DPI |
| Wireless option type |
Optional, enabled with purchase of a hardware accessory |
| Driver updates |
Most recent printer drivers and software for all supported operating systems available at http:///support; if no access to the Internet, see support flyer that came in printer box |
| Duplex supported media size |
A4, A5, B5 (JIS), executive (JIS), 16K |
| Media handling |
Sheetfed |
| Memory technology |
Memory Enhancement technology (MEt) |
| Control panel |
2.29 x 5.33 cm 4-Line LCD display, 3 light-emitting diode (LED) indicator lights (Ready, Data, Attention), buttons (10 numeric keys, Information, Return, Stop/Cancel, OK, Toggle up/down) |
| Maximum paper trays |
6 |
| Media size (tray 2) |
A4, A5, B5 (JIS), letter, legal, executive, statement, 16K, Executive (JIS), 148 x 210 to 216 x 356 mm |
| Media size (tray 3) |
A4, A5, B5 (JIS), letter, legal, executive, statement, 16K, Executive (JIS), 148 x 210 to 216 x 356 mm |
| Media type and capacity (tray 2) |
sheets: 500 |
| Media type and capacity (tray 3) |
sheets: 500 |
| Media weight (tray 2) |
60 to 120 g/m² |
| Media weight (tray 3) |
60 to 120 g/m² |
| Paper handling optional/input |
Optional 500-sheet input tray, optional 1500-sheet input tray (up to 5 additional trays for up to 3600-sheet input capacity), optional 75-sheet envelope feeder, optional custom media cassette (Tray 2) |
| Paper handling standard/input |
100-sheet multipurpose tray, 500-sheet input tray |
| Paper handling standard/output |
100-sheet rear output bin, 500-sheet top output bin |
| Security management description |
Management security: SNMPv3, SSL/TLS (HTTPS), 802.1X authentication (EAP- PEAP, EAP-TLS), IPsec/Firewall with Kerberos, Certificate, and PreShared Key Authentication: Wireless network security (Requires HP Jetdirect 690n Wireless Print Server): 802.1x (EA |
| Upgrade type |
Printer firmware can be remotely upgraded, Jetdirect firmware can be remotes upgraded |
| Paper handling optional/output |
Optional 500-sheet stacker, optional 500-sheet stapler/stacker, optional 500-sheet 5-bin mailbox |
| Downloadable software |
Microsoft Windows Installer, HP PCL 6, HP PCL 5e, HP postscript level 3 emulation, HP Web Jetadmin, Macintosh Installer, Macintosh PostScript, PostScript Printer Description (PPD) files, IBM drivers, Model scripts, OS/2 PCL 5 or PCL 6 printer driver, OS/2 |
| Package dimensions (W x D x H) |
789.9 x 599.4 x 541 mm (31.1 x 23.6 x 21.3") |
| Pallet dimensions (W x D x H) |
1201.4 x 800.1 x 2308.9 mm (47.3 x 31.5 x 90.9") |
| Pallet weight |
259 kg (571 lbs) |
| Weight |
57.54 lb |
| Acoustic pressure emissions bystander (active, print, copy or scan) |
58 dB(A) |
| Duplex binding |
N |
| First page out (black&white, A4, ready) |
8.5 s |
| First page out (black&white, letter, ready) |
8.5 s |
| First page out (black&white, letter, sleep) |
12 s |
| Media sizes supported (imperial) |
Letter, legal, executive, statement, 8.5 x 13 in, custom 3.0 x 5.0 to 8.5 x 14 in, envelope (Com10, Monarch #7-3/4) |
| Operating altitude (imperial) |
Up to 10,000 ft |
| Package weight |
65.26 lb |
| Print speed (black, best quality, letter) |
< 52 |
| Acoustic power emissions (ready) |
4.1 B(A) |
| Acoustic pressure emissions bystander (ready) |
27 dB(A) |
| Automatic paper sensor |
N |
| Document delivery speed (A4) |
As fast as 16 sec |
| Document delivery speed (letter) |
As fast as 16 sec |
| Document delivery speed note |
The time it takes to complete a typical office print job (described by InfoTrends as three to five pages long) coming out of low power mode with Instant-on Technology. |
| First page out (black&white, letter, cold start) |
As fast as 68 |
| Maximum input capacity (priority feed) |
Sheets: 100, Envelopes: 10 |
| Number of cartons per pallet |
2 |
| Number of layers per pallet |
4 |
| SureSupply connection type |
Direct and Network |
| SureSupply software driver |
N |
| SureSupply supported |
Y |
| Typical electricity consumption (TEC) number |
4.286 kWh/Week |
| Product weight optional (imperial) |
194.4 lb (with all possible options) |
| Product weight optional (metric) |
79.37 kg (with all possible options) |
| Recommended media weight (duplex, imperial) |
16 to 32 lb |
| Standard media sizes (duplex, imperial) |
Letter, legal, executive, custom 5.8 x 8.3 to 8.5 x 14 in |
| Pallet dimensions (W x D x H) (imperial) |
1201.4 x 800.1 x 2308.9 mm (47.3 x 31.5 x 90.9") |
| Pallet weight (imperial) |
259 kg (571 lbs) |
| Weight (imperial) |
57.54 lb |
| Package weight (imperial) |
29.6 kg (65.3 lbs) |
| Standard output capacity for transparencies |
600 sheets |
| PictBridge |
N |
| Size (imperial) |
41.9 cm (16.5") |
| Package dimensions (WxDxH) |
790 x 600 x 540 mm |
| Design |
| Display |
LCD |
| Colour of product |
Black, Grey |
| Product colour |
Black, Grey |
| Certification |
IEC 60950-1
EN 60950-1+A11 (EU)
IEC 60825-1+A1+A2
UL/cUL
GS
EN 60825-1+A1+A2 GB4943-2001
|
| Performance |
| Processor clock speed |
540 MHz |
| Built-in processor |
Y |
| Source data-sheet |
|
| Processor frequency |
540 MHz |
| Processor model |
Motorola ColdFire V5e |
| Internal memory |
128 MB |
| HDD capacity |
Optional |
| Card reader integrated |
N |
| Energy Star certified |
N |
| Blue Angel certified |
N |
| Certification |
IEC 60950-1\nEN 60950-1+A11 (EU)\nIEC 60825-1+A1+A2\nUL/cUL\nGS\nEN 60825-1+A1+A2 GB4943-2001\n |
| Packaging content |
| Bundled software |
Print drivers and installation software on CD-ROM: HP PCL 5e, HP PCL 6, Postscript, Postscript Printer Description files, HP LaserJet Utility (Mac), Macintosh software |
| Processor |
| Built-in processor |
Y |
| Processor model |
Motorola ColdFire V5e |
| Processor frequency |
540 MHz |
| Features |
| Maximum duty cycle |
225000 pages per month |
| Number of print cartridges |
1 |
| Recommended duty cycle |
3000 |
| Logistics data |
| Pallet weight |
260 kg |
| Number of cartons per pallet |
2 |
| Number of layers per pallet |
4 |
| Quantity per pallet |
16 pc(s) |
| Pallet gross weight |
260 kg |
| Master (outer) cases per pallet |
2 pc(s) |
| Layers per pallet |
4 pc(s) |
| Products per pallet |
16 pc(s) |
| Input & output capacity |
| Standard input capacity |
600 sheets |
| Standard output capacity |
600 sheets |
| Maximum output capacity |
600 sheets |
| Total input capacity |
600 sheets |
| Total output capacity |
600 sheets |
| Packaging data |
| Package weight |
29.6 kg |
| Packaging content |
| Bundled software |
Print drivers and installation software on CD-ROM: HP PCL 5e, HP PCL 6, Postscript, Postscript Printer Description files, HP LaserJet Utility (Mac), Macintosh software |
