| Weight & dimensions |
| Weight |
4.65 kg |
| Package weight |
6.19 kg |
| System requirements |
| Minimum system requirements |
Internet Explorer 5.01 Service Pack 2; USB port; CD-ROM drive; SVGA monitor (800 x 600, 16-bit colour) |
| Mac compatibility |
Y |
| Minimum hard disk space |
500 MB |
| Minimum RAM |
64 MB |
| Minimum processor |
Intel Pentium II 233 MHz |
| Compatible operating systems |
Windows 98, 98 SE, Me, 2000, XP Home, XP Professional; Mac OS X 10.2 |
| Minimum storage drive space |
500 MB |
| Power |
| Power consumption (typical) |
21 W |
| Scanning |
| Maximum scan size |
220 x 315 mm |
| Colour scanning |
Y |
| Input colour depth |
48 bit |
| Film scanning |
Y |
| Gray scale levels |
256 |
| Greyscale levels |
256 |
| Operational conditions |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage relative humidity (H-H) |
0 - 90% |
| Certificates |
| Energy Star certified |
Y |
| Electromagnetic compatibility |
EU (CE Declaration of Conformity), US (FCC Declaration), Australia (ACA), New Zealand (ACA), Russia (GOST), Korea (MIC), Taiwan (BSMI), China (CCC) |
| Other features |
| Network ready |
N |
| Dimensions (WxDxH) |
505 x 300 x 100 mm |
| Package dimensions (WxDxH) |
586 x 186 x 453 mm |
| Scan speed (4x6, colour photo) |
9 sec |
| Power requirements |
100 - 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz) |
| TWAIN version |
1.9 |
| Safety |
CB Report IEC 60950-1:2001, North America UL/c-UL UL60950-1, Europe EN60950-1:2001 and TÜV-Rheinland GS, Russia GOST, China CCC, Taiwan BSMI |
| Media types supported |
Paper (banner, inkjet, photo, plain), envelopes, labels, cards (greeting, index), 3-D objects, 35-mm slides and negatives (using transparent materials adapter), iron-on transfers |
| Product dimensions when open (LxWxD) |
50.5 cm (19.9") |
| Size |
50.5 cm (19.9") |
| Dynamic range |
3.8 dB |
| Non-operating relative humidity (non-condensing) |
0 - 90% |
| Scan speed (OCR, A4) |
30 sec |
| Scan speed in preview mode |
6 sec |
| Scan input modes |
Front-panel Scan, Scan Film, Copy, Scan to Share (with HP Instant Share or e-mail or with HP Image Zone software); user application via TWAIN; Transparent Materials Adapter (transmissive scans of film materials) |
| I/O ports |
1 Hi-Speed USB - compatible with USB 2.0 specifications |
| Minimum system requirements for Macintosh |
Macintosh; USB; 128 MB RAM; Mac OS X v10.2, 250 MB; SVGA monitor (800 x 600, 16-bit colour); CD-ROM drive |
| Maximum dimensions (W x D x H) |
505 x 300 x 95 mm |
| Pallet dimensions (W x D x H) |
1201 x 1000 x 1952 mm |
| Pallet weight |
259 kg |
| Quantity per pallet |
40 pc(s) |
| Power management |
Universal AC adapter used worldwide: 100 to 240-VAC (50/60 Hz) input, 24-VDC 1500mA (36 watts) output, Energy Star efficiency level IV |
| Recommended operating temperature range (T-T) |
10 - 35 °C |
| Image scaling/enlargement range |
10 - 2000% in 1% increments |
| Control panel |
4 front-panel buttons (Copy, Scan, Scan film, Scan to share) |
| Remote front panel software |
Y |
| Transparency adapter |
Built-in Transparent Materials Adapter (TMA) for up to four 35 mm slides or six negative frames |
| Technical features |
Four one-touch buttons for fast access to key functions: Scan, Scan Film, Copy, Scan to Share.
Leading resolution at this price – scan at 4800 x 9600 dpi hardware resolution and 48-bit colour.
Remove red-eye, dust and scratches; enhance detail in dark are |
| Maximum scan area |
21.6 cm (8.5") |
| Number of cartons per pallet |
10 |
| Number of layers per pallet |
4 |
| Package dimensions (W x D x H) |
586 x 185.9 x 452.9 mm (23.1 x 7.32 x 17.8") |
| Package weight |
13.62 lb |
| Weight |
10.6 lb |
| Exifprint supported |
Yes, Version 2.2 |
| Scan resolution enhanced disclaimer (long) |
What is the maximum resolution at which I can scan? HP Scanjet scanning systems will allow you to specify a resolution of up to 999,999 enhanced dpi. In addition, by using lower dpi and high-scale factors (enlarging the image using dimension or resize too |
| Scan resolution enhanced disclaimer (short) |
The maximum dpi at which you can scan is limited by available computer memory, disk space and other system factors. |
| Package weight (imperial) |
6.18 kg (13.6 lbs) |
| Pallet dimensions (W x D x H) (imperial) |
1198.9 x 1000.8 x 1955.8 mm (47.2 x 39.4 x 77") |
| Pallet weight (imperial) |
258.5 kg (570 lbs) |
| Weight (imperial) |
10.6 lb |
| Size (imperial) |
50.5 cm (19.9") |
| Maximum scan area (imperial) |
21.6 cm (8.5") |
| Pallet gross weight |
259 kg |
| Design |
| Scanner type |
Flatbed scanner |
| Packaging content |
| Bundled software |
HP Image Zone software for Windows and Macintosh, IRIS Readiris OCR software, HP Instant Share, HP Image Editor (with faded colour restoration, HP auto red-eye removal, HP adaptive lighting, dust and scratch removal capabilities) |
| Performance |
| Sensor type |
CCD |
| Light source |
CCFL |
| Scan file formats |
BMP,PCX,PDF,TIFF,TXT |
| Button functions |
Scan |
| Internal memory |
512 MB |
| Processor clock speed |
1800 MHz |
| Source data-sheet |
|
| Processor frequency |
1800 MHz |
| Technical details |
| Sustainability certificates |
ENERGY STAR |
| Logistics data |
| Quantity per pallet |
40 pc(s) |
| Number of cartons per pallet |
10 |
| Number of layers per pallet |
4 |
| Products per pallet |
40 pc(s) |
| Master (outer) cases per pallet |
10 pc(s) |
| Layers per pallet |
4 pc(s) |
| Packaging data |
| Package dimensions (WxDxH) |
586 x 186 x 453 mm |
| Package weight |
6.19 kg |
| Package dimensions (W x D x H) |
586 x 185.9 x 452.9 mm (23.1 x 7.32 x 17.8") |
| Package weight (imperial) |
6.18 kg (13.6 lbs) |
