| Weight & dimensions |
| Width |
488 mm |
| Depth |
340 mm |
| Height |
83 mm |
| Package weight |
54 kg |
| Weight |
3.4 kg |
| Ports & interfaces |
| Standard interfaces |
USB 2.0 |
| USB port |
Y |
| USB version |
2.0 |
| System requirements |
| Mac compatibility |
Y |
| Minimum hard disk space |
4096 MB |
| Minimum RAM |
1024 MB |
| Minimum processor |
800 MHz |
| Compatible operating systems |
Microsoft Windows 2000, XP Professional / Home Edition, Windows Vista
Mac OS X 10.1.5, 10.2 + |
| Windows operating systems supported |
Y |
| Mac operating systems supported |
Y |
| USB required |
Y |
| Minimum storage drive space |
4096 MB |
| Power |
| Power supply type |
AC |
| Power consumption (typical) |
36 W |
| Input frequency |
50/60 |
| Input voltage |
100-240 V |
| AC input frequency |
50 - 60 Hz |
| Scanning |
| Maximum scan size |
216 x 279 mm |
| Optical scanning resolution |
2400 x 2400 DPI |
| Colour scanning |
Y |
| Duplex scanning |
N |
| Input colour depth |
48 bit |
| Film scanning |
Y |
| Gray scale levels |
256 |
| Flatbed scan speed (b/w, A4) |
10 sec/page |
| Greyscale levels |
256 |
| Operational conditions |
| Operating temperature (T-T) |
5 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
5 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Paper handling |
| Scanning media types supported |
Card stock, Envelopes, Photo paper, Plain paper |
| Maximum scan area (ADF) |
210 x 356 mm |
| Minimum scan area (ADF) |
89 x 127 mm |
| Auto Document Feeder (ADF) media weight |
60 - 90 g/m² |
| Multi feed detection |
N |
| ISO A-series sizes (A0...A9) |
A4,A5 |
| Letter |
Y |
| Legal |
Y |
| ISO B-series sizes (B0...B9) |
B5 |
| Maximum ISO A-series paper size |
A4 |
| Certificates |
| Energy Star certified |
Y |
| Electromagnetic compatibility |
EMC |
| Input capacity |
| Auto document feeder (ADF) input capacity |
50 sheets |
| Other features |
| Network ready |
N |
| Package dimensions (WxDxH) |
580 x 250 x 476 mm |
| Weight |
12.6 |
| Scan speed (black and white drawing) |
< 31 s |
| Scan speed (4x6, colour photo) |
< 28 s |
| Scan speed (auto document feed) |
8 ppm/4 ipm |
| TWAIN version |
1.8 |
| Safety |
IEC 60950-1, CCC, GOST, BSMI, NOM |
| Product dimensions when open (LxWxD) |
48.8 cm (19.2") |
| Size |
48.8 cm (19.2") |
| Scan speed (OCR, A4) |
< 48 s |
| Scan speed in preview mode |
10 s |
| Minimum system requirements for Macintosh |
Mac OS X v 10.2: PowerPC G3, G4, G5, Intel Core processor; 128 MB RAM; 240 MB
Mac OS X v 10.5: PowerPC G4, G5 / Intel Core Processor; 512 MB RAM; 7 GB |
| Maximum dimensions (W x D x H) |
488 x 340 x 162 mm |
| Pallet dimensions (W x D x H) |
1200 x 1000 x 2232 mm |
| Pallet weight |
273 kg |
| Quantity per pallet |
40 pc(s) |
| Recommended operating temperature range (T-T) |
5 - 40 °C |
| Image scaling/enlargement range |
10 - 2400% |
| Remote front panel software |
Y |
| Maximum scan area (Auto Document Feeder) |
8.5 x 14 |
| Maximum scan area |
21.6 cm (8.5") |
| Number of cartons per pallet |
8 |
| Number of layers per pallet |
6 |
| Package dimensions (W x D x H) |
475 x 579.1 x 248.9 mm (18.7 x 22.8 x 9.8") |
| Package weight |
17.8 |
| Exifprint supported |
2.2 |
| Maximum scan area (ADF) (imperial) |
215.9 x 355.6 mm (8.5 x 14") |
| Package weight (imperial) |
8.07 kg (17.8 lbs) |
| Pallet dimensions (W x D x H) (imperial) |
1198.9 x 1000.8 x 2232.7 mm (47.2 x 39.4 x 87.9") |
| Weight (imperial) |
5.72 kg (12.6 lbs) |
| Size (imperial) |
48.8 cm (19.2") |
| Maximum scan area (imperial) |
21.6 cm (8.5") |
| Design |
| Scanner type |
Flatbed scanner |
| Colour of product |
Grey |
| Product colour |
Grey |
| Packaging content |
| Bundled software |
HP Photosmart, I.R.I.S. Readiris Pro, NewSoft Presto! PageManager |
| Drivers included |
Y |
| Performance |
| Sensor type |
CCD |
| Scan file formats |
BMP, GIF, HTM, JPG, PCX, PDF, PNG, RTF, TIFF |
| Scan to |
File, Image |
| Scan drivers |
TWAIN |
| Source data-sheet |
|
| Technical details |
| Sustainability certificates |
ENERGY STAR |
| Logistics data |
| Quantity per pallet |
40 pc(s) |
| Number of cartons per pallet |
8 |
| Number of layers per pallet |
6 |
| Packaging data |
| Package dimensions (WxDxH) |
580 x 250 x 476 mm |
| Package weight |
54 kg |
| Package dimensions (W x D x H) |
475 x 579.1 x 248.9 mm (18.7 x 22.8 x 9.8") |
| Package weight (imperial) |
8.07 kg (17.8 lbs) |
