Weight & dimensions |
Width |
502 mm |
Depth |
415 mm |
Height |
162 mm |
Weight |
6.7 kg |
Package weight |
8.21 kg |
Ports & interfaces |
Standard interfaces |
USB 2.0 |
USB port |
Y |
USB version |
2.0 |
System requirements |
Mac compatibility |
Y |
Minimum RAM |
1024 MB |
Minimum processor |
800 MHz |
Compatible operating systems |
Microsoft Windows 7, Windows Vista, Windows XP (32-bit / 64-bit), Windows XP x64, Windows 2000
Mac OS X v10.4.11, 10.5, 10.6 |
Windows operating systems supported |
Y |
USB required |
Y |
Mac operating systems supported |
Y |
Power |
Power consumption (typical) |
60 W |
Input frequency |
50/60 |
Input voltage |
100-240 V |
AC input frequency |
50 - 60 Hz |
Power supply type |
AC |
Scanning |
Maximum scan size |
216 x 292 mm |
Optical scanning resolution |
2400 x 2400 DPI |
Colour scanning |
Y |
Input colour depth |
48 bit |
Film scanning |
Y |
Gray scale levels |
256 |
Greyscale levels |
256 |
Operational conditions |
Operating temperature (T-T) |
10 - 35 °C |
Storage temperature (T-T) |
-40 - 60 °C |
Operating relative humidity (H-H) |
15 - 80% |
Storage relative humidity (H-H) |
0 - 90% |
Paper handling |
Maximum ISO A-series paper size |
A4 |
Scanning media types supported |
Envelopes, Photo paper, Plain paper |
Maximum scan area (ADF) |
216 x 356 mm |
Minimum scan area (ADF) |
148 x 148 mm |
Auto Document Feeder (ADF) media weight |
50 - 120 g/m² |
Multi feed detection |
Y |
ISO A-series sizes (A0...A9) |
A4,A5 |
Letter |
Y |
ISO B-series sizes (B0...B9) |
B5 |
Certificates |
Energy Star certified |
Y |
Electromagnetic compatibility |
EU (EMC Directive), US and Canada (FCC Rules), Australia and New Zealand (ACMA), China (CCC), Korea (MIC), Taiwan (BSMI), Russia (GOST), South Africa (I.C.A.S.A.) |
Input capacity |
Auto document feeder (ADF) input capacity |
50 sheets |
Other features |
Network ready |
N |
Package dimensions (WxDxH) |
588 x 248 x 547 mm |
Scan speed (4x6, colour photo) |
< 22 s |
Scan speed (auto document feed) |
15 ppm/6 ipm |
TWAIN version |
1.9 |
Safety |
IEC 60950-1, CCC, GOST, BSMI, NOM |
Product dimensions when open (LxWxD) |
50.2 cm (19.8") |
Size |
50.2 cm (19.8") |
Scan speed (OCR, A4) |
< 31 s |
Scan speed in preview mode |
N |
Minimum system requirements for Macintosh |
Mac OS X v10.4.11, 10.5, 10.6 |
Maximum dimensions (W x D x H) |
502 x 415 x 168 mm |
Pallet dimensions (W x D x H) |
1219.2 x 1016 x 2315 mm |
Pallet weight |
284 kg |
Quantity per pallet |
32 pc(s) |
Recommended operating temperature range (T-T) |
10 - 35 °C |
Image scaling/enlargement range |
12 - 2400% |
Transparency adapter |
2 x 35 mm |
Output resolutions |
75, 100, 150, 200, 300, 400, 600, 1200, 2400 |
Document weight maximum (Auto document Feeder, imperial) |
32 lbs |
Document weight minimum (Auto Document Feeder, imperial) |
13 lbs |
Maximum scan area (Auto Document Feeder) |
8.5 x 14 |
Maximum scan area |
21.6 cm (8.5") |
Media weight imperial (Auto Document Feeder) |
13 - 32 lbs |
Minimum scan area (Auto Document Feeder) |
147.3 x 147.3 mm (5.8 x 5.8") |
Number of cartons per pallet |
8 |
Number of layers per pallet |
4 |
Package dimensions (W x D x H) |
588 x 247.9 x 547.1 mm (23.1 x 9.76 x 21.5") |
Package weight |
18.1 |
Stacking number for carton |
8 |
Stacking number for pallet |
2 |
Weight |
14.6 |
Duplex ADF scanning |
Y |
Maximum scan area (ADF) (imperial) |
215.9 x 355.6 mm (8.5 x 14") |
Package weight (imperial) |
8.21 kg (18.1 lbs) |
Pallet dimensions (W x D x H) (imperial) |
1219.2 x 1016 x 2313.9 mm (48 x 40 x 91.1") |
Pallet weight (imperial) |
283.5 kg (625 lbs) |
Weight (imperial) |
6.62 kg (14.6 lbs) |
Size (imperial) |
50.2 cm (19.8") |
Maximum scan area (imperial) |
21.6 cm (8.5") |
Design |
Scanner type |
Flatbed & ADF scanner |
Colour of product |
Black, Grey |
Product colour |
Grey |
Packaging content |
Bundled software |
EMC ISIS/TWAIN, PaperPort, Readiris Pro, Presto! BizCard
Readiris Pro, Presto! PageManager |
Drivers included |
Y |
Performance |
Sensor type |
CCD |
Light source |
CCFL |
Scan file formats |
PDF, JPG, BMP, TIFF, TXT, RTF, FPX, PNG, PCX, GIF |
Daily duty cycle (max) |
500 pages |
Maximum duty cycle |
500 pages per month |
Scan to |
File, Image |
Scan drivers |
ISIS,TWAIN |
Technical details |
Sustainability certificates |
ENERGY STAR |
Logistics data |
Quantity per pallet |
32 pc(s) |
Number of cartons per pallet |
8 |
Number of layers per pallet |
4 |
Packaging data |
Package dimensions (WxDxH) |
588 x 248 x 547 mm |
Package weight |
8.21 kg |
Package dimensions (W x D x H) |
588 x 247.9 x 547.1 mm (23.1 x 9.76 x 21.5") |
Package weight (imperial) |
8.21 kg (18.1 lbs) |
