| Weight & dimensions |
| Weight |
6.7 kg |
| Width |
502 mm |
| Depth |
415 mm |
| Height |
168 mm |
| Package weight |
8.21 kg |
| Ports & interfaces |
| Standard interfaces |
Ethernet,USB 2.0 |
| System requirements |
| Minimum system requirements |
Microsoft Windows 7 ready (for more information go to /go/windows7. Some features may not be available), Windows Vista: 1.3 GHz processor, 1 GB RAM; Windows XP Home, XP Professional: 1.3 GHz processor, 512 MB RAM; Windows 2000: 800 MHz processor, 256 MB R |
| Mac compatibility |
N |
| Minimum hard disk space |
450 MB |
| Minimum RAM |
256 MB |
| Minimum processor |
800 MHz |
| Compatible operating systems |
Microsoft Windows 7 ready. For more information go to http:///go/Windows7. Some features may not be available. Windows Vista, Windows Vista x64, Windows XP Home, Windows XP Professional, Windows XP x64, Windows 2000 |
| Windows operating systems supported |
Windows 2000,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64 |
| USB required |
Y |
| Minimum storage drive space |
450 MB |
| Power |
| Power consumption (typical) |
60 W |
| Input frequency |
50/60 |
| Input voltage |
100-240 V |
| AC input frequency |
50/60 Hz |
| Scanning |
| Maximum scan size |
216 x 292 mm |
| Optical scanning resolution |
2400 x 2400 DPI |
| Colour scanning |
Y |
| Duplex scanning |
Y |
| Enhanced scan resolution |
19200 x 19200 DPI |
| Input colour depth |
48 bit |
| Gray scale levels |
65536 |
| ADF scan speed (b/w, A4) |
15 ppm |
| Duplex ADF scan speed (b/w, A4) |
6 ipm |
| Film scanning |
N |
| Greyscale levels |
65536 |
| Operational conditions |
| Operating temperature (T-T) |
50 - 95 °F |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
15 - 80% |
| Storage relative humidity (H-H) |
0 - 90% |
| Paper handling |
| Maximum ISO A-series paper size |
A4 |
| Scanning media types supported |
Card stock,Envelopes,Photo paper,Plain paper |
| Auto Document Feeder (ADF) media weight |
50 to 120 |
| Multi feed detection |
Y |
| ISO A-series sizes (A0...A9) |
A4,A5 |
| Maximum scan area (ADF) |
216 x 356 mm |
| Minimum scan area (ADF) |
148 x 148 mm |
| Certificates |
| Energy Star certified |
Y |
| Electromagnetic compatibility |
Class B; EU (EMC Directive), US and Canada (FCC Rules), Australia and New Zealand (ACMA), China (CCC), Korea (MIC), Taiwan (BSMI), Russia (GOST), South Africa (I.C.A.S.A.) |
| Input capacity |
| Auto document feeder (ADF) input capacity |
50 sheets |
| Other features |
| Quantity per pallet |
32 pc(s) |
| Scan time |
50 s |
| TWAIN version |
Version 1.9 |
| Safety |
IEC 60950-1 First Edition (2001); national derivatives; associated voluntary and mandatory certifications: China (CCC), Russia (GOST), Taiwan (BSMI), Mexico (NOM) |
| Image formats supported |
BMP,GIF,JPG,PCX,PNG,TIF |
| Pallet weight |
284 kg |
| Image scaling/enlargement range |
12 to 2400% in 1% increments |
| Transparency adapter |
TMA |
| Duplex ADF scanning |
Y |
| Dimensions (WxDxH) |
502 x 415 x 168 mm |
| Package dimensions (WxDxH) |
588 x 248 x 547 mm |
| Power requirements |
Input voltage 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3%) |
| Scan media weight |
120 |
| Media types supported |
Paper (plain, inkjet, photo), envelopes, cards (index, greeting), 3-D objects
A4, A5, custom |
| Number of cartons per pallet |
8 |
| Number of layers per pallet |
4 |
| Product dimensions when open (LxWxD) |
50.2 cm (19.8") |
| Size |
50.2 cm (19.8") |
| Scan input modes |
Front-panel scan to HP Scanning Software; HP Document Copy; software scan using HP Scanning Software; user application via TWAIN, ISIS, or WIA drivers |
| I/O ports |
1 Ethernet, 1 Hi-Speed USB 2.0 |
| Maximum dimensions (W x D x H) |
502 x 415 x 168 mm |
| Pallet dimensions (W x D x H) |
1000 x 1200 x 2312 mm |
| Recommended operating temperature range (T-T) |
10 - 35 °C |
| Control panel |
5 front-panel buttons (Cancel, Copy, Power, Scan, Setup), navigation and selection buttons (Up arrow, Down arrow, Back, OK), 10 key number pad for PIN entry |
| Technical features |
HP scanning technology for automatic deskew, rotation and cropping.
Task-based user interface with shortcuts to common tasks, e.g. scan-to-PDF, scan-to-email.
Integrated networking with simple Ethernet connectivity for multiple users.
Adaptive Lighting, A |
| Output resolutions |
75, 100, 150, 200, 300, 400, 600, 1200, 2400 |
| Minimum scan size |
Flatbed, no minimum |
| Dimension note (imperial) |
With automatic document feeder |
| Dimension note (metric) |
With automatic document feeder |
| Maximum scan area (ADF) (imperial) |
215.9 x 355.6 mm (8.5 x 14") |
| Maximum scan area |
21.6 cm (8.5") |
| Minimum scan area (Auto Document Feeder) |
147.3 x 147.3 mm (5.8 x 5.8") |
| Package dimensions (W x D x H) |
588 x 247.9 x 547.1 mm (23.1 x 9.76 x 21.5") |
| Package weight (imperial) |
8.21 kg (18.1 lbs) |
| Pallet dimensions (W x D x H) (imperial) |
1219.2 x 1016 x 2313.9 mm (48 x 40 x 91.1") |
| Pallet weight (imperial) |
283.5 kg (625 lbs) |
| Stacking number for carton |
8 |
| Stacking number for pallet |
2 pc(s) |
| Weight (imperial) |
14.8 lb |
| Security management description |
Optional 4-digit user PIN security enabled |
| Size (imperial) |
50.2 cm (19.8") |
| Maximum scan area (imperial) |
21.6 cm (8.5") |
| Pallet gross weight |
284 kg |
| Design |
| Scanner type |
Flatbed scanner |
| Colour of product |
Black, Silver |
| Product colour |
Black,Silver |
| Packaging content |
| Bundled software |
For Windows: HP Scan software; EMC ISIS/TWAIN drivers; Nuance PaperPort 11*; I.R.I.S. Readiris Pro OCR*; NewSoft Presto! BizCard*; *Note: product ships with 3 licenses of all Third Party Software. Additional licenses can be purchased. |
| Performance |
| Sensor type |
CCD |
| Daily duty cycle (max) |
500 pages |
| Light source |
CCFL |
| Scan file formats |
BMP, FPX, GIF, JPG, PCX, PDF, PNG, RTF, TIFF, TXT |
| Scan drivers |
ISIS,TWAIN,WIA |
| Supported network protocols |
TCP/IP |
| Technical details |
| Sustainability certificates |
ENERGY STAR |
| Networking |
| Supported network protocols |
TCP/IP |
| Logistics data |
| Quantity per pallet |
32 pc(s) |
| Number of cartons per pallet |
8 |
| Number of layers per pallet |
4 |
| Products per pallet |
32 pc(s) |
| Master (outer) cases per pallet |
8 pc(s) |
| Layers per pallet |
4 pc(s) |
| Packaging data |
| Package dimensions (WxDxH) |
588 x 248 x 547 mm |
| Package weight |
8.21 kg |
| Package dimensions (W x D x H) |
588 x 247.9 x 547.1 mm (23.1 x 9.76 x 21.5") |
| Package weight (imperial) |
8.21 kg (18.1 lbs) |
