| Processor |
| Processor family |
Intel® Xeon® Gold |
| Processor cores |
8 |
| Processor socket |
LGA 3647 (Socket P) |
| Processor lithography |
14 nm |
| Cooler included |
N |
| Processor model |
6234 |
| Processor base frequency |
3.3 GHz |
| Processor operating modes |
64-bit |
| Processor generation |
2nd Generation Intel® Xeon® Scalable |
| Component for |
Server/workstation |
| Processor series |
Intel Xeon Gold 6000 Series |
| Processor threads |
16 |
| Processor boost frequency |
4 GHz |
| Processor cache |
25 MB |
| Processor cache type |
L3 |
| Thermal Design Power (TDP) |
130 W |
| Stepping |
B1 |
| Bus type |
UPI |
| Processor codename |
Cascade Lake |
| Operational conditions |
| Tcase |
79 °C |
| Memory |
| Memory channels |
Hexa-channel |
| Maximum internal memory supported by processor |
1000 GB |
| Memory types supported by processor |
DDR4-SDRAM |
| Memory clock speeds supported by processor |
2933 MHz |
| ECC |
Y |
| Graphics |
| On-board graphics card |
N |
| Discrete graphics card |
N |
| Other features |
| Compatibility |
DL360 Gen10 |
| Processor special features |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Y |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® AES New Instructions (Intel® AES-NI) |
Y |
| Enhanced Intel SpeedStep Technology |
Y |
| Intel Trusted Execution Technology |
Y |
| Intel® Speed Shift Technology |
Y |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Intel TSX-NI |
Y |
| Intel 64 |
Y |
| Intel Virtualization Technology (VT-x) |
Y |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| Intel Turbo Boost Max Technology 3.0 |
N |
| AVX-512 Fused Multiply-Add (FMA) units |
2 |
| Intel® Deep Learning Boost (Intel® DL Boost) |
Y |
| Intel® Speed Select technology - Performance Profile (Intel® SST-PP) |
N |
| Intel® Resource Director Technology (Intel® RDT) |
Y |
| Intel® Volume Management Device (VMD) |
Y |
| Intel® Run Sure Technology |
Y |
| Mode-based Execute Control (MBE) |
Y |
| Intel® Optane™ DC Persistent Memory Supported |
Y |
| Intel® vPro™ Platform Eligibility |
Y |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) |
N |
| Features |
| Execute Disable Bit |
Y |
| Maximum number of PCI Express lanes |
48 |
| PCI Express slots version |
3.0 |
| Supported instruction sets |
AVX-512 |
| Scalability |
4S |
| Embedded options available |
N |
