| Weight & dimensions |
| Width (with stand) |
714 mm |
| Depth (with stand) |
227 mm |
| Height (with stand) |
603.4 mm |
| Weight (with stand) |
8.4 kg |
| Width (without stand) |
714 mm |
| Depth (without stand) |
47 mm |
| Height (without stand) |
421.2 mm |
| Power |
| Energy efficiency class (SDR) |
F |
| Energy efficiency class (HDR) |
F |
| Energy consumption (SDR) per 1000 hours |
32 kWh |
| Power consumption (typical) |
39 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (max) |
210 W |
| Power consumption (off) |
0.3 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power supply type |
Internal |
| Energy efficiency scale |
A to G |
| European Product Registry for Energy Labelling (EPREL) code |
1339168 |
| Display |
| Display diagonal |
80 cm (31.5") |
| Display resolution |
3840 x 2160 pixels |
| Native aspect ratio |
16:9 |
| Display technology |
LCD |
| Touchscreen |
No |
| HD type |
4K Ultra HD |
| Panel type |
IPS |
| Response time |
5 ms |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1000:1 |
| Maximum refresh rate |
60 Hz |
| Display number of colours |
1.07 billion colours |
| LED backlight |
Yes |
| Backlight type |
Edge LED |
| Display brightness (peak) |
350 cd/m² |
| Display brightness (typical) |
350 cd/m² |
| Display brightness |
350 cd/m² |
| Response time measurement type |
GTG (Gray to Gray) |
| Display surface |
Matt |
| Anti-glare screen |
Yes |
| Supported graphics resolutions |
1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 2560 x 1440, 3840 x 2160, 640 x 480 (VGA), 720 x 400, 720 x 480, 800 x 600 (SVGA) |
| Aspect ratio |
16:9 |
| Contrast ratio (dynamic) |
8000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.18 x 0.18 mm |
| Pixel density |
140 ppi |
| Horizontal scan range |
30 - 135 kHz |
| Vertical scan range |
30 - 60 Hz |
| Viewable size, horizontal |
69.7 cm |
| Viewable size, vertical |
39.2 cm |
| Display diagonal (metric) |
80 cm |
| Haze rate |
25% |
| Surface hardness |
3H |
| Colour depth |
10 bit |
| Colour gamut standard |
sRGB |
| Colour gamut |
99% |
| sRGB coverage (typical) |
99% |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
20 - 80% |
| Ports & interfaces |
| Built-in USB hub |
Yes |
| HDMI |
Yes |
| Headphone out |
No |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| USB Type-A downstream ports quantity |
3 |
| USB Type-C downstream ports quantity |
1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
65 W |
| HDMI ports quantity |
1 |
| HDMI version |
2.0 |
| DisplayPorts quantity |
1 |
| DisplayPort version |
1.4 |
| HDCP |
Yes |
| Ergonomics |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Height adjustment |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Adjustable height (max) |
15 cm |
| Pivot |
Yes |
| Pivot angle |
-90 - 90° |
| Swivelling |
Yes |
| Swivel angle range |
-45 - 45° |
| Tilt adjustment |
Yes |
| Tilt angle range |
-5 - 20° |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Simplified Chinese, Traditional Chinese, German, Dutch, English, Spanish, French, Italian, Japanese, Portuguese, Russian |
| Number of OSD languages |
11 |
| Other features |
| Country of origin |
China |
| Weight |
8.4 kg |
| Compliance certificates |
CECP, CCC, CB, EAC, BIS, Federal Communications Commission (FCC), CE, BSMI |
| Ethernet LAN (RJ-45) ports |
1 |
| UNSPSC-code |
43211902 |
| Design |
| Market positioning |
Business |
| Product colour |
Black |
| Detachable stand |
Yes |
| Feet colour |
Silver, Black |
| Performance |
| NVIDIA G-SYNC |
No |
| AMD FreeSync |
No |
| Fast charging |
Yes |
| Flicker-free technology |
Yes |
| Low Blue Light technology |
Yes |
| HP segment |
Business |
| Multimedia |
| Built-in speaker(s) |
Yes |
| Built-in camera |
No |
| Number of speakers |
2 |
| RMS rated power |
6 W |
| Packaging data |
| Package width |
820 mm |
| Package depth |
527 mm |
| Package height |
161 mm |
| Package weight |
11.8 kg |
| Package type |
Box |
| Warranty card |
Yes |
| Brand-specific features |
| HP GTIN (EAN/UPC) with options |
(ABB) 196786296918; (ABU) 196786296932 |
| HP GTIN (EAN/UPC) |
196786296918, 196786296932 |
| Packaging content |
| Stand included |
Yes |
| Cables included |
AC |
| Quick start guide |
Yes |
| Network |
| Ethernet LAN |
Yes |
| Remotely operated |
Yes |
| Sustainability |
| Sustainability certificates |
ENERGY STAR, EPEAT, TCO |
| Sustainable technologies and materials |
Outside box and corrugated cushions are 100% sustainably sourced and recyclable; Contains ocean-bound recycled plastic; 75% ITE-derived closed loop plastic; At least 25% recycled metal |
