| Weight & dimensions |
| Display width |
1122.7 mm |
| Display depth |
55 mm |
| Display height |
643.6 mm |
| Display weight |
11.8 kg |
| Display |
| Display diagonal |
125.7 cm (49.5") |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
No |
| Panel type |
VA |
| Native aspect ratio |
16:9 |
| Response time |
9.5 ms |
| Contrast ratio (typical) |
5000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colours |
| Pixel pitch |
0.285 x 0.285 mm |
| Active display area (W x H) |
1095.8 x 616.4 mm |
| Display diagonal (metric) |
125.7 cm |
| Maximum frame rate |
60 fps |
| Horizontal scan range |
28 - 160 kHz |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| RGB colour space |
sRGB |
| Packaging data |
| Package width |
1261 mm |
| Package depth |
1261 mm |
| Package height |
761 mm |
| Package weight |
16.2 kg |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Power |
| Power consumption (typical) |
112 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (off) |
0.3 W |
| Energy efficiency class (SDR) |
G |
| Energy consumption (SDR) per 1000 hours |
112 kWh |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency scale |
A to G |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| DisplayPorts quantity |
1 |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| HDMI version |
2.0 |
| VGA (D-Sub) input ports |
0 |
| DisplayPorts out |
1 |
| DisplayPort version |
1.2 |
| USB ports quantity |
2 |
| USB version |
2.0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| PC Audio in |
Yes |
| RS-232C |
Yes |
| Remote (IR) input |
1 |
| Remote (IR) output |
1 |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash) |
| Audio Return Channel (ARC) |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Other features |
| Quick start guide |
Yes |
| Housing material |
Metal |
| Design |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Yes |
| Orientation |
Horizontal/Vertical |
| Panel mounting interface |
400 x 400 mm |
| Bezel width (bottom) |
1.49 cm |
| Bezel width (side) |
1.49 cm |
| Bezel width (top) |
1.49 cm |
| Bezel colour |
Black |
| Anti-glare screen |
Yes |
| Performance |
| Purpose |
Universal |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
15 |
| On Screen Display (OSD) languages |
Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Polish, Russian, Swedish |
| Operating hours (hours/days) |
24/7 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Mean time between failures (MTBF) |
44000 h |
| Technical details |
| Compliance certificates |
RoHS |
| Computer system |
| Built-in processor |
Yes |
| Processor manufacturer |
ARM |
| Processor family |
ARM Cortex |
| Processor architecture |
ARM Cortex-A73 |
| Processor cores |
4 |
| Internal memory |
4 GB |
| On-board graphics card model |
ARM Mali-G52 |
| Internal storage capacity |
32 GB |
| Operating system installed |
Android 11 |
| Certificates |
| Certification |
CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH |
| Packaging content |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC, HDMI, RS-232 |
| Logistics data |
| Harmonized System (HS) code |
85285210 |
