| Weight & dimensions |
| Width (with stand) |
1488.5 mm |
| Depth (with stand) |
87.5 mm |
| Height (with stand) |
896.5 mm |
| Weight (with stand) |
35 kg |
| Display |
| Display diagonal |
165.1 cm (65") |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
400 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
Yes |
| Panel type |
IPS |
| Touchscreen technology |
PureTouch-IR |
| Number of simultaneous touchpoints |
40 |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
4000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colours |
| Pixel pitch |
0.372 x 0.372 mm |
| Active display area (W x H) |
1428.5 x 803.5 mm |
| Display diagonal (metric) |
163.9 cm |
| Horizontal scan range |
30 - 135 kHz |
| Surface hardness |
7H |
| Glass thickness |
3 mm |
| Glass film |
AG/AR Film |
| Packaging data |
| Package width |
1628 mm |
| Package depth |
208 mm |
| Package height |
1005 mm |
| Package volume |
44700 cm³ |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
32 W |
| Power |
| Power consumption (typical) |
138 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (off) |
0.3 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Ports & interfaces |
| HDMI ports quantity |
4 |
| DVI port |
No |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| HDMI version |
2.0 |
| HDMI input ports quantity |
3 |
| HDMI output ports quantity |
1 |
| VGA (D-Sub) input ports |
1 |
| USB ports quantity |
5 |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
3 |
| Ethernet LAN (RJ-45) ports |
2 |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| RS-232 interface |
Yes |
| RS-232C |
Yes |
| Remote (IR) input |
1 |
| Audio Return Channel (ARC) |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
-20 - 60% |
| Design |
| Product design |
Kiosk design |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Yes |
| Orientation |
Horizontal |
| Panel mounting interface |
600 x 400 mm |
| Bezel width (bottom) |
4.5 cm |
| Bezel width (side) |
1.65 cm |
| Bezel width (top) |
1.65 cm |
| Performance |
| Purpose |
Commercial |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Czech, Danish, German, English, Spanish, Finnish, French, Italian, Polish, Russian, Slovenian |
| Operating hours (hours/days) |
24/7 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Mean time between failures (MTBF) |
50000 h |
| Computer system |
| Built-in processor |
Yes |
| Processor manufacturer |
ARM |
| Processor family |
ARM Cortex |
| Processor model |
A55 |
| Processor architecture |
ARM Cortex-A55 |
| Processor cores |
4 |
| Internal memory |
8 GB |
| On-board graphics card model |
ARM Mali-G52 |
| Internal storage capacity |
32 GB |
| Operating system installed |
Android 11 |
| Certificates |
| Certification |
CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, EPA 8.0 |
| Packaging content |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
HDMI, Power, USB |
| Wi-Fi module included |
Yes |
