| Weight & dimensions |
| Display width |
1710 mm |
| Display depth |
87 mm |
| Display height |
1016 mm |
| Display weight |
51.8 kg |
| Width |
1710 mm |
| Depth |
87 mm |
| Height |
1016 mm |
| Weight |
51.8 kg |
| Display |
| Display diagonal |
190.5 cm (75") |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
Yes |
| Panel type |
IPS |
| Touchscreen technology |
PureTouch-IR |
| Number of simultaneous touchpoints |
40 |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colours |
| Pixel pitch |
0.4296 x 0.4296 mm |
| Active display area (W x H) |
1650 x 928 mm |
| Display diagonal (metric) |
189.3 cm |
| Horizontal scan range |
30 - 135 kHz |
| Surface hardness |
7H |
| Glass thickness |
3.2 mm |
| Packaging data |
| Package width |
1860 mm |
| Package depth |
185 mm |
| Package height |
1125 mm |
| Package weight |
63 kg |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
60 W |
| Power |
| Power consumption (typical) |
217 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (off) |
0.3 W |
| Energy efficiency class (SDR) |
G |
| Energy consumption (SDR) per 1000 hours |
188 kWh |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency scale |
A to G |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| DisplayPorts quantity |
1 |
| USB port |
Yes |
| HDMI input ports quantity |
2 |
| HDMI output ports quantity |
1 |
| DisplayPort version |
1.2 |
| USB ports quantity |
6 |
| USB version |
2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB connector type |
USB Type-A, USB Type-C, USB Type-B |
| USB 2.0 Type-B ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
100 W |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Ethernet LAN (RJ-45) ports |
2 |
| RS-232C |
Yes |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash) |
| OPS module slot |
Yes |
| Audio Return Channel (ARC) |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Other features |
| Quick start guide |
Yes |
| Bluetooth |
Yes |
| Bluetooth version |
5.0 |
| Brightness |
500 cd/m² |
| Compatible operating systems |
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Power supply type |
Internal |
| Design |
| Product design |
Interactive flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Yes |
| Orientation |
Horizontal |
| Panel mounting interface |
800 x 400 mm |
| Bezel width (bottom) |
4.1 cm |
| Bezel width (side) |
1.65 cm |
| Bezel width (top) |
1.65 cm |
| Bezel colour |
Black |
| Anti-glare screen |
Yes |
| Positioning accuracy |
1 mm |
| Performance |
| Purpose |
Education |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
13 |
| On Screen Display (OSD) languages |
Czech, Danish, German, English, Spanish, Estonian, Finnish, French, Hungarian, Italian, Lithuanian, LAT, Norwegian, Dutch, Polish, Russian, Swedish, Ukrainian, CAT |
| Operating hours (hours/days) |
24/7 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Mean time between failures (MTBF) |
50000 h |
| Technical details |
| OPS slot |
1 |
| Sustainability certificates |
ErP |
| Warranty period |
5 year(s) |
| Compliance certificates |
CB, CE, EAC, REACH, RoHS, TÜV mark, WEEE |
| Audio in (mini jack) |
Yes |
| Playback media |
Y |
| User controls |
general settings (input, volume, backlight), audio (volume, bass, treble, balance, sound mode, mute), screen settings (aspect ratio, pixel shift), display settings (brightness, contrast, hue, sharpness, display mode colour temp), settings (wireless & netw |
| Computer system |
| Computer system |
Yes |
| Built-in processor |
Yes |
| Processor architecture |
ARM Cortex-A53+Cortex-A72 |
| Internal memory |
8 GB |
| On-board graphics card model |
ARM Mali-G52 |
| Internal storage capacity |
128 GB |
| Operating system installed |
Android |
| Operating system version |
14 |
| Packaging content |
| Remote control included |
Yes |
| Stylus pen |
Yes |
| Number of stylus pens |
4 |
| Cables included |
AC, USB, HDMI |
| Logistics data |
| Products per pallet |
4 pc(s) |
| Network |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
1000 Mbit/s |
| Wi-Fi standards |
Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11b, 802.11g, 802.11a |
