Weight & dimensions |
Width |
1957 mm |
Height |
1160 mm |
Depth |
87 mm |
Weight |
66.8 kg |
Technical details |
Horizontal scan range |
30 - 80 kHz |
Sustainability certificates |
CE, REACH, RoHS, WEEE |
Power |
Power consumption (typical) |
315 W |
Power consumption (standby) |
0.5 W |
Power consumption (off) |
0.3 W |
AC input voltage |
180-240 V |
AC input frequency |
50/60 Hz |
Ports & interfaces |
Wi-Fi |
Y |
Bluetooth |
Y |
Ethernet LAN |
Y |
Ethernet LAN data rates |
1000 Mbit/s |
HDCP |
Y |
USB 2.0 ports quantity |
4 |
HDMI ports quantity |
2 |
HDMI version |
2.0 |
Ethernet LAN (RJ-45) ports |
2 |
Bluetooth version |
5.0 |
RS-232 ports |
1 |
Audio |
Built-in speaker(s) |
Y |
Number of built-in speakers |
2 |
Speaker power |
10 W |
Operational conditions |
Operating temperature (T-T) |
0 - 40 °C |
Storage temperature (T-T) |
-20 - 60 °C |
Packaging data |
Package width |
2123 mm |
Package depth |
1345 mm |
Package height |
280 mm |
Package weight |
91 kg |
Quantity per pack |
1 pc(s) |
System requirements |
Windows operating systems supported |
Y |
Mobile operating systems supported |
Android, iOS |
Packaging content |
Cables included |
AC, HDMI, USB |
Batteries included |
Y |
Ergonomics |
VESA mounting |
Y |
Panel mounting interface |
800 x 600 mm |
Wall mountable |
Y |
Projector |
Built-in projector |
N |
Performance |
Remote control included |
Y |
Mean time between failures (MTBF) |
50000 h |
Pen |
Pen included |
Y |
Processor |
Built-in processor |
Y |
Processor cores |
4 |
Memory |
User memory |
16 GB |
RAM capacity |
2 GB |
Features |
Display diagonal |
2.18 m (86") |
Touchscreen |
Y |
Working area |
1895 x 1066 mm |
Display brightness |
350 cd/m² |
Display number of colours |
1.07 billion colours |
Display resolution |
3840 x 2160 pixels |
HD type |
4K Ultra HD |
Panel type |
IPS |
Contrast ratio (typical) |
1200:1 |
Contrast ratio (dynamic) |
3500:1 |
Response time |
8 ms |
Touch technology |
Multi-touch |
Touchscreen type |
Infrared |
Number of simultaneous touchpoints |
20 |
Viewing angle, horizontal |
178° |
Viewing angle, vertical |
178° |
Pixel pitch |
0.494 x 0.494 mm |
Product colour |
Black |
Graphics adapter |
Mali-G31 MP2 |
Operating system installed |
Android 9.0 |
