| Weight & dimensions |
| Display width |
968 mm |
| Display depth |
54 mm |
| Display height |
557.5 mm |
| Display weight |
8.4 kg |
| Width |
968 mm |
| Depth |
54 mm |
| Height |
557.5 mm |
| Weight |
8.4 kg |
| Display |
| Display diagonal |
108 cm (42.5") |
| Display technology |
LCD |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
350 cd/m² |
| HD type |
Full HD |
| Panel type |
IPS |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colours |
| Pixel pitch |
0.49 x 0.49 mm |
| Active display area (W x H) |
940.9 x 529.3 mm |
| Display diagonal (metric) |
108 cm |
| Horizontal scan range |
30 - 83 kHz |
| Native refresh rate |
60 Hz |
| Haze rate |
1% |
| Packaging data |
| Package width |
1075 mm |
| Package depth |
127 mm |
| Package height |
683 mm |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Power |
| Power consumption (typical) |
53 W |
| Power consumption (standby) |
0.3 W |
| Power consumption (off) |
0.3 W |
| Energy efficiency class (SDR) |
G |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
53.4 kWh |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency scale |
A to G |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| USB port |
Yes |
| HDMI version |
2.0 |
| VGA (D-Sub) input ports |
1 |
| USB ports quantity |
1 |
| USB version |
2.0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| RS-232C |
Yes |
| Remote (IR) input |
1 |
| Remote (IR) output |
1 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Other features |
| Quick start guide |
Yes |
| Power supply type |
Internal |
| Cable management |
Yes |
| Design |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Orientation |
Horizontal |
| Panel mounting interface |
200 x 200 mm |
| Bezel width (bottom) |
1.4 cm |
| Bezel width (side) |
1.4 cm |
| Bezel width (top) |
1.4 cm |
| Bezel colour |
Black |
| Performance |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
11 |
| On Screen Display (OSD) languages |
Traditional Chinese, Czech, German, English, Spanish, French, Italian, Japanese, Dutch, Polish, Russian |
| Operating hours (hours/days) |
18/7 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Mean time between failures (MTBF) |
50000 h |
| Technical details |
| Sustainability certificates |
ErP |
| Compliance certificates |
CB, CE, EAC, REACH, RoHS, TÜV mark, WEEE |
| Audio in (mini jack) |
Yes |
| Playback media |
Y |
| User controls |
picture (picture format, colour temp., noise reduction, dynamic contrast, gamma, brightness, black level, colour, contrast, hue, sharpness, RGB range, reset), Sound (treble, bass, balance, speaker, audio output, reset), general settings 1 (menu languages, |
| Features |
| Suitable for indoor use |
Yes |
| Certificates |
| Certification |
CB, CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH |
| Packaging content |
| Remote control included |
Yes |
| Batteries included |
No |
| Cables included |
AC, HDMI, RS-232 |
| Network |
| Ethernet LAN |
Yes |
