| Weight & dimensions |
| Width (with stand) |
387 mm |
| Depth (with stand) |
239.5 mm |
| Height (with stand) |
378 mm |
| Weight (with stand) |
5.4 kg |
| Power |
| Energy efficiency class (SDR) |
E |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
12.5 kWh |
| Power consumption (typical) |
20 W |
| Power consumption (standby) |
1.5 W |
| Power consumption (off) |
0.3 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power supply type |
Internal |
| Energy efficiency scale |
A to G |
| Display |
| Display diagonal |
43.2 cm (17") |
| Display resolution |
1280 x 1024 pixels |
| Native aspect ratio |
5:4 |
| Display technology |
LCD |
| Touchscreen |
Yes |
| HD type |
SXGA |
| Panel type |
TN |
| Response time |
5 ms |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1000:1 |
| Display number of colours |
16.7 million colours |
| Touchscreen technology |
Resistive |
| Touch technology |
Single-touch |
| Number of simultaneous touchpoints |
1 |
| Display brightness (typical) |
250 cd/m² |
| Display brightness |
195 cd/m² |
| Viewing angle, horizontal |
170° |
| Viewing angle, vertical |
160° |
| Pixel pitch |
0.264 x 0.264 mm |
| Horizontal scan range |
31.5 - 80 kHz |
| Viewable size, horizontal |
33.8 cm |
| Viewable size, vertical |
27 cm |
| Display diagonal (metric) |
43 cm |
| Ports & interfaces |
| HDMI |
Yes |
| USB Touch port |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Audio input |
Yes |
| HDCP |
Yes |
| Ergonomics |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Cable management |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Tilt angle range |
-5 - 90° |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Other features |
| International Protection (IP) code |
IP54 |
| Compatible operating systems |
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Brightness |
195 cd/m² |
| Active display area (W x H) |
338 x 270 mm |
| Weight |
5.4 kg |
| Height |
378 mm |
| Width |
387 mm |
| Depth |
239.5 mm |
| Compliance certificates |
CE, cULus, EAC, REACH, RoHS, UKCA, VCCI, WEEE |
| Mean time between failures (MTBF) |
50000 h |
| User controls |
contrast, brightness, lock mode (power, OSD), auto adjust, OSD, H. position, V. position, H-size, fine, OSD H. position, OSD V. position, OSD timeout, reset, input select, OSD language, colour temperature, volume, mute |
| Touch method |
stylus, finger, glove, glove (latex) |
| Control panel |
Menu, Scroll up/ Brightness, Scroll down/ Mute, Select, Power |
| Design |
| Product colour |
Black |
| Front bezel colour |
Black |
| Detachable stand |
No |
| Multimedia |
| Built-in speaker(s) |
Yes |
| Built-in camera |
No |
| Number of speakers |
2 |
| RMS rated power |
2 W |
| Packaging content |
| Stand included |
Yes |
| Cables included |
AC, USB, HDMI, DisplayPort, Audio |
| Quick start guide |
Yes |
| Sustainability |
| Sustainability certificates |
ErP |
