| Weight & dimensions |
| Width (with stand) |
743 mm |
| Depth (with stand) |
61 mm |
| Height (with stand) |
437 mm |
| Weight (with stand) |
10 kg |
| Width (without stand) |
742.5 mm |
| Depth (without stand) |
61 mm |
| Height (without stand) |
437 mm |
| Weight (without stand) |
10 kg |
| Power |
| Energy efficiency class (SDR) |
F |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
27.5 kWh |
| Power consumption (typical) |
32 W |
| Power consumption (standby) |
0.7 W |
| Power consumption (off) |
0.3 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power supply type |
Internal |
| Energy efficiency scale |
A to G |
| Display |
| Display diagonal |
80 cm (31.5") |
| Display resolution |
1920 x 1080 pixels |
| Native aspect ratio |
16:9 |
| Display technology |
LED |
| Touchscreen |
Yes |
| HD type |
Full HD |
| Panel type |
VA |
| Response time |
8 ms |
| Screen shape |
Flat |
| Contrast ratio (typical) |
3000:1 |
| Display number of colours |
16.7 million colours |
| Touchscreen type |
Kiosk |
| Touchscreen technology |
Projected capacitive system |
| Touch technology |
Multi-touch |
| Number of simultaneous touchpoints |
30 |
| Display brightness (peak) |
500 cd/m² |
| Display brightness (typical) |
500 cd/m² |
| Display brightness |
460 cd/m² |
| Response time measurement type |
GTG (Gray to Gray) |
| Contrast ratio (dynamic) |
3000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.3637 x 0.3637 mm |
| Horizontal scan range |
30 - 68 kHz |
| Vertical scan range |
47 - 63 Hz |
| Viewable size, horizontal |
69.8 cm |
| Viewable size, vertical |
39.3 cm |
| Display diagonal (metric) |
80 cm |
| Surface hardness |
7H |
| Colour depth |
8 bit |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Ports & interfaces |
| HDMI |
Yes |
| USB Touch port |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| HDCP |
Yes |
| Ergonomics |
| VESA mounting |
Yes |
| Cable lock slot |
No |
| Panel mounting interface |
200 x 200 mm |
| Wall mountable |
Yes |
| Cable management |
Yes |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Number of OSD languages |
7 |
| Plug and Play |
Yes |
| Other features |
| International Protection (IP) code |
IP65 |
| Compatible operating systems |
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Positional accuracy |
2 mm |
| Brightness |
460 cd/m² |
| Active display area (W x H) |
698.4 x 392.8 mm |
| Weight |
10 kg |
| Height |
437 mm |
| Width |
743 mm |
| Depth |
61 mm |
| Compliance certificates |
CE, EAC, REACH, RoHS, UKCA, WEEE |
| Mean time between failures (MTBF) |
50000 h |
| User controls |
Picture (contrast, brightness, H.position, V.position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (timeout, poition, H-Position, V-Position, touch switch), option (reset, language, source select, display mode, factory) |
| Touch method |
finger, glove (latex), capacitive stylus |
| Control panel |
Menu, Scroll up/ Brightness, Scroll down/ Mute, Select, Power |
| Optical drive player software |
Y |
| Design |
| Market positioning |
Office |
| Product colour |
Black |
| Housing material |
Metal |
| Front bezel colour |
Black |
| Glass thickness |
3 mm |
| Performance |
| NVIDIA G-SYNC |
No |
| AMD FreeSync |
No |
| Operating hours (hours/days) |
24/7 |
| Multimedia |
| Built-in speaker(s) |
No |
| Built-in camera |
No |
| Packaging data |
| Package width |
890 mm |
| Package depth |
155 mm |
| Package height |
630 mm |
| Package weight |
13.3 kg |
| Packaging content |
| Cables included |
AC, USB, HDMI |
| Quick start guide |
Yes |
| Sustainability |
| Sustainability certificates |
ErP |
