| Networking |
| Bluetooth |
Y |
| Bluetooth version |
5 |
| MU-MIMO |
Y |
| Maximum data transfer rate |
2400 Mbit/s |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| System requirements |
| Compatible operating systems |
Windows 10, 64-bit*|Linux* |
| Weight & dimensions |
| Weight |
2.8 g |
| Ports & interfaces |
| Host interface |
PCI Express |
| Operational conditions |
| Maximum operating temperature |
80 °C |
| Operating temperature (T-T) |
0 - 80 °C |
| Other features |
| Form factor |
M.2 2230, M.2 1216 |
| Supported Under vPro |
Y |
| Interface type |
Wi-Fi(PCIe), BT(USB) |
| Product type |
Wireless |
| Compliance |
FIPS, FISMA |
| Launch date |
Q2'19 |
| Product brief URL |
https://www.intel.com/content/dam/www/public/us/en/documents/product-briefs/wi-fi-6-ax200-module-brief.pdf |
| Status |
Launched |
| Maximum operating temperature |
80 °C |
| Harmonized System (HS) code |
8517620090 |
| Export Control Classification Number (ECCN) |
5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) |
G165483 |
| Product series |
Intel® Wireless Products |
| Product codename |
Cyclone Peak |
| Processor family |
Intel Wi-Fi 6 Products |
| Design |
| Form factor |
M.2 2230, M.2 1216 |
| Antenna type |
2x2 |
| Technical details |
| Harmonized System (HS) code |
8517620090 |
