| Weight & dimensions |
| Width |
82.5 mm |
| Depth |
350 mm |
| Height |
23.4 mm |
| Weight |
355 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| HDMI ports quantity |
2 |
| Microphone in |
Yes |
| Headphone outputs |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB Power Delivery |
Yes |
| USB Power Delivery revision |
3.0 |
| USB Power Delivery up to |
100 W |
| VGA (D-Sub) ports quantity |
1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Power |
| Input current |
5 A |
| Output voltage |
20 V |
| Output current |
0.9 A |
| Power consumption (typical) |
4.5 W |
| Power plug type |
Type C |
| Packaging content |
| Cables included |
USB Type-C |
| AC adapter included |
No |
| Quick start guide |
Yes |
| Manual |
Yes |
| Packaging content |
1 x USB-C™ Triple Monitor Docking Station, 1 x Quick Installation Guide, 1 x 100W USB-C™ Power Adapter |
| Other features |
| Cable length |
0.45 m |
| Maximum operating temperature |
48 °C |
| Operational conditions |
| Operating temperature (T-T) |
0 - 48 °C |
| Storage temperature (T-T) |
-10 - 65 °C |
| Operating relative humidity (H-H) |
0 - 85% |
| Storage relative humidity (H-H) |
0 - 85% |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Performance |
| Product colour |
Black, Silver |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash), SD |
| HD type |
4K Ultra HD |
| Number of displays supported |
3 |
| Maximum refresh rate |
60 Hz |
| Hub interfaces |
DisplayPort, HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, VGA |
| Housing material |
Aluminium |
| Country of origin |
Taiwan |
| Technical details |
| Warranty period |
2 year(s) |
| Software |
| Windows operating systems supported |
Windows 10, Windows 11, Yes |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, MacOS, Yes |
| Packaging data |
| Quantity per pack |
1 pc(s) |
| Package width |
88 mm |
| Package depth |
358 mm |
| Package height |
28 mm |
| Package weight |
433 g |
