| Printing |
| Print speed (black, normal quality, A4/US Letter) |
21 ppm |
| Print speed (colour, normal quality, A4/US Letter) |
21 ppm |
| Warm-up time |
32 s |
| Time to first page (black, normal) |
11 s |
| Time to first page (colour, normal) |
12.5 s |
| Colour |
Y |
| Print technology |
Laser |
| Duplex printing |
Y |
| Maximum resolution |
9600 x 600 DPI |
| Duplex printing mode |
Auto |
| Print resolution colour |
1200 x 1200 DPI |
| Print resolution black |
1200 x 1200 DPI |
| Duplex print speed (black, normal quality, A4/US Letter) |
11 ppm |
| Duplex print speed (colour, normal quality, A4/US Letter) |
11 ppm |
| Economical printing |
Y |
| Weight & dimensions |
| Width |
410 mm |
| Depth |
410 mm |
| Height |
329 mm |
| Weight |
21 kg |
| Input capacity |
| Standard input capacity |
250 sheets |
| Maximum input capacity |
550 sheets |
| Multi-Purpose tray capacity |
50 sheets |
| Number of standard paper trays |
1 |
| Paper input type |
Cassette,Paper tray |
| Output capacity |
| Standard output capacity |
150 sheets |
| Print technology |
| Colour |
Y |
| Maximum resolution |
9600 x 600 DPI |
| Maximum duty cycle |
30000 pages per month |
| Duplex printing |
Y |
| Number of print cartridges |
3 |
| Standard printer languages |
Microsoft XPS,PCL 5c,PCL 6,PCL XL,PostScript 3 |
| Print technology |
Laser |
| Printing colours |
Black,Cyan,Magenta,Yellow |
| Ports & interfaces |
| Standard interfaces |
Ethernet, USB 2.0 |
| Direct printing |
Y |
| USB port |
Y |
| System requirements |
| Windows operating systems supported |
Y |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks |
| Linux operating systems supported |
Y |
| Memory |
| Internal memory |
512 MB |
| Maximum internal memory |
512 MB |
| Card reader integrated |
Y |
| Compatible memory cards |
SD,SDHC |
| Power |
| Power consumption (typical) |
345 W |
| AC input voltage |
220 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (standby) |
0.9 W |
| Power consumption (ready) |
33 W |
| Power consumption (printing) |
345 W |
| Energy Star Typical Electricity Consumption (TEC) |
0.69 kWh/week |
| Sound emission |
| Printing noise level |
45.4 dB |
| Standby acoustic emission |
30 dB |
| Paper handling |
| Maximum ISO A-series paper size |
A4 |
| ISO A-series sizes (A0...A9) |
A4,A5,A6 |
| ISO B-series sizes (B0...B9) |
B5,B6 |
| Non-ISO print media sizes |
Legal, Letter |
| Standard tray media weight |
60 - 163 g/m² |
| Multi-Purpose Tray media weight |
60 - 220 g/m² |
| Duplex media weight |
60 - 120 g/m² |
| Custom media width |
70 - 216 mm |
| Custom media length |
148 - 356 mm |
| Paper tray media types |
Plain paper |
| Maximum print size |
216 x 356 mm |
| Paper tray media weight |
60 - 163 g/m² |
| Operational conditions |
| Operating temperature (T-T) |
10 - 32.5 °C |
| Storage temperature (T-T) |
-20 - 40 °C |
| Operating relative humidity (H-H) |
15 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating altitude |
0 - 3500 m |
| Non-operating altitude |
0.6 - 15000 m |
| Networking |
| Ethernet LAN |
Y |
| Wi-Fi |
N |
| Network ready |
Y |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Near Field Communication (NFC) |
N |
| Bluetooth |
N |
| Mobile printing technologies |
Apple AirPrint,Google Cloud Print,Kyocera Mobile Print,Mopria Print Service |
| Certificates |
| Energy Star certified |
Y |
| Certification |
GS, TÃœV, CE, ISO 9001, ISO 14001 |
| Design |
| Product colour |
Black, White |
| Built-in display |
Y |
| Display |
LCD |
| Market positioning |
Home & office |
| Colour display |
N |
| Display number of lines |
2 lines |
| Control type |
Buttons |
| Certification |
GS, TÜV, CE, ISO 9001, ISO 14001 |
| Performance |
| Internal memory |
512 MB |
| Maximum internal memory |
512 MB |
| Built-in processor |
Y |
| Printing noise level |
45.4 dB |
| Card reader integrated |
Y |
| Compatible memory cards |
SD,SDHC |
| Processor family |
ARM Cortex |
| Processor model |
A9 |
| Processor frequency |
800 MHz |
| Standby acoustic emission |
30 dB |
| Energy Star certified |
Y |
| Certification |
GS, TÜV, CE, ISO 9001, ISO 14001 |
| Sound pressure level (printing) |
48 dB |
| Sound pressure level (quiet mode) |
44 dB |
| Sound power level (standby) |
30 dB |
| Processor |
| Built-in processor |
Y |
| Processor family |
ARM Cortex |
| Processor model |
A9 |
| Processor frequency |
800 MHz |
| Features |
| Maximum duty cycle |
30000 pages per month |
| Printing colours |
Black, Cyan, Magenta, Yellow |
| Number of print cartridges |
4 |
| Page description languages |
Microsoft XPS,PCL 5c,PCL 6,PCL XL,PostScript 3 |
| Recommended duty cycle |
1000 - 2000 pages per month |
| Replacement cartridges |
TK-5220K (1.200 pagina's)
TK-5220C, TK-5220M, TK-5220Y (1.200 pagina's)
TK-5230K (2.600 pagina's)
TK-5230C, TK-5230M, TK-5230Y (2.200 pagina's) |
| Input & output capacity |
| Standard input capacity |
250 sheets |
| Standard output capacity |
150 sheets |
| Paper input type |
Cassette, Paper tray |
| Maximum input capacity |
550 sheets |
| Multi-Purpose tray capacity |
50 sheets |
| Number of standard paper trays |
1 |
| Total number of input trays |
1 |
| Total input capacity |
250 sheets |
| Total output capacity |
150 sheets |
| Paper tray 1 input capacity |
250 sheets |
| Multi-Purpose tray |
Y |
| Multi-Purpose tray input capacity |
50 sheets |
| Maximum number of input trays |
2 |
| Maximum output capacity |
150 sheets |
| Packaging data |
| Package width |
529 mm |
| Package depth |
567 mm |
| Package height |
460 mm |
| Package weight |
27 kg |
| Packaging content |
| Cartridge(s) included |
Y |
| Included cartridge capacity (black) |
1200 pages |
| Included cartridge capacity (CMY) |
1200 pages |
| Power cord included |
Y |
| USB cable included |
N |
| Certification |
| Waste Electrical and Electronic Equipment (WEEE) compliance |
Y |
| Technical details |
| Sustainability certificates |
Blue Angel, CE, REACH, RoHS, ENERGY STAR |
| Sustainability |
| Sustainability certificates |
Blue Angel, CE, REACH, RoHS, ENERGY STAR |
