| Processor |
| Processor family |
Intel Core Ultra 7 |
| Processor manufacturer |
Intel |
| Processor model |
255HX |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cores |
20 |
| Processor threads |
20 |
| Processor boost frequency |
5.2 GHz |
| Performance cores |
8 |
| Efficient cores |
12 |
| Performance-core Max Turbo Frequency |
5.2 GHz |
| Efficient-core Max Turbo Frequency |
4.5 GHz |
| Performance-core base frequency |
2.4 GHz |
| Efficient-core base frequency |
1.8 GHz |
| Processor cache |
30 MB |
| Processor base power |
55 W |
| Maximum turbo power |
160 W |
| Memory |
| Internal memory |
16 GB |
| Maximum internal memory |
64 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
1 x 16 GB |
| Memory clock speed |
5600 MHz |
| Ports & interfaces |
| USB 2.0 ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| DisplayPorts quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| Power |
| Power supply |
500 W |
| Power supply input voltage |
100 - 240 V |
| Power supply input frequency |
50/60 Hz |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating altitude |
0 - 3048 m |
| Non-operating altitude |
0 - 12192 m |
| Weight & dimensions |
| Width |
211 mm |
| Depth |
490.4 mm |
| Height |
414 mm |
| Weight |
15 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Wi-Fi standards |
Wi-Fi 7 (802.11be) |
| Antenna type |
2x2 |
| Bluetooth |
Yes |
| Bluetooth version |
5.4 |
| Certificates |
| Certification |
RoHS |
| Operating system/software |
| Operating system installed |
Windows 11 Home |
| Operating system architecture |
64-bit |
| Operating system language |
English |
| Software |
| Operating system installed |
Windows 11 Home |
| Operating system architecture |
64-bit |
| Operating system language |
English |
| Storage |
| Total storage capacity |
1 TB |
| Optical drive type |
No |
| Storage media |
SSD |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Card reader integrated |
No |
| Graphics |
| Discrete graphics card |
Yes |
| On-board graphics card |
Yes |
| Discrete graphics card model |
NVIDIA GeForce RTX 5060 |
| On-board graphics card model |
Intel Graphics |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics card memory |
8 GB |
| Discrete graphics memory type |
GDDR7 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel Graphics |
| Design |
| Chassis type |
Tower |
| Product colour |
Black |
| Colour name |
Eclipse Black |
| Volume |
30 L |
| Performance |
| Product type |
PC |
| Audio chip |
Realtek ALC623 |
| Audio system |
High Definition Audio |
| Trusted Platform Module (TPM) |
Yes |
| Neural processor unit (NPU) |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
33 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
8 TOPs |
| Display |
| Display included |
No |
