| Processor |
| Processor family |
Intel Core Ultra 5 |
| Processor manufacturer |
Intel |
| Processor model |
225T |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cores |
10 |
| Processor threads |
10 |
| Processor boost frequency |
4.9 GHz |
| Performance cores |
6 |
| Efficient cores |
4 |
| Performance-core Max Turbo Frequency |
4.9 GHz |
| Efficient-core Max Turbo Frequency |
4.4 GHz |
| Performance-core base frequency |
2.5 GHz |
| Efficient-core base frequency |
1.9 GHz |
| Processor cache |
20 MB |
| Processor cache type |
Smart Cache |
| Processor base power |
35 W |
| Maximum turbo power |
114 W |
| Memory |
| Internal memory |
16 GB |
| Maximum internal memory |
64 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
1 x 16 GB |
| Memory slots |
2x SO-DIMM |
| Memory clock speed |
5600 MHz |
| Memory channels |
Dual-channel |
| Ports & interfaces |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| DisplayPort version |
1.4a |
| HDMI version |
2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| Power |
| Power supply |
90 W |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating altitude |
0 - 3048 m |
| Non-operating altitude |
0 - 12192 m |
| Weight & dimensions |
| Width |
179 mm |
| Depth |
182.9 mm |
| Height |
36.5 mm |
| Weight |
1.18 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel® I219-LM |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
| WLAN controller manufacturer |
Intel |
| WLAN controller model |
Intel Wi-Fi 6 AX203 |
| Antenna type |
2x2 |
| Bluetooth |
Yes |
| Bluetooth version |
5.2 |
| Wake-on-LAN ready |
Yes |
| Certificates |
| Compliance certificates |
RoHS |
| Certification |
ENERGY STAR,TCO,RoHS |
| Operating system/software |
| Operating system installed |
Windows 11 Pro |
| Operating system language |
English, German, Dutch, French, Italian |
| Software |
| Operating system installed |
Windows 11 Pro |
| Operating system language |
English, German, Dutch, French, Italian |
| Storage |
| Total storage capacity |
512 GB |
| Optical drive type |
No |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
512 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
512 GB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Card reader integrated |
No |
| Graphics |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel® Graphics |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel® Graphics |
| Packaging content |
| Mouse included |
Yes |
| Mouse connectivity |
Wired |
| Keyboard included |
Yes |
| Design |
| Chassis type |
Mini PC |
| Product colour |
Black |
| Colour name |
Raven black |
| Volume |
1 L |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Performance |
| Product type |
Mini PC |
| Motherboard chipset |
Intel B860 |
| Password protection |
Yes |
| Password protection type |
BIOS, HDD, Power on, Supervisor |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Built-in speaker(s) |
Yes |
| Packaging data |
| Package width |
250 mm |
| Package depth |
490 mm |
| Package height |
128 mm |
| Package weight |
3.2 kg |
| Sustainability |
| Sustainability certificates |
ENERGY STAR, TCO |
| Neural processor unit (NPU) |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, ONNX RT, OpenVINO, WebNN, Windows ML |
| Total processor performance up to |
23 TOPs |
| NPU performance up to |
13 TOPs |
| Display |
| Display included |
No |
| Keyboard |
| Keyboard connectivity |
Wired |
| Audio |
| Audio chip |
Realtek ALC233VB |
| Audio system |
High Definition Audio |
| Number of speakers |
1 |
