| Processor |
| Processor family |
Intel® Core™ i3 |
| Processor manufacturer |
Intel |
| Processor model |
i3-13100T |
| Processor generation |
Intel Core i3-13xxx |
| Processor cores |
4 |
| Processor threads |
8 |
| Processor boost frequency |
4.2 GHz |
| Performance cores |
4 |
| Efficient cores |
0 |
| Performance-core Max Turbo Frequency |
4.2 GHz |
| Performance-core base frequency |
2.5 GHz |
| Processor cache |
12 MB |
| Processor cache type |
Smart Cache |
| Processor base power |
35 W |
| Maximum turbo power |
69 W |
| Memory |
| Internal memory |
16 GB |
| Maximum internal memory |
16 GB |
| Internal memory type |
DDR4-SDRAM |
| Memory layout (slots x size) |
2 x 8 GB |
| Memory slots |
2x SO-DIMM |
| Memory clock speed |
3200 MHz |
| Memory channels |
Dual-channel |
| Ports & interfaces |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| Power |
| Power supply |
90 W |
| Power supply input voltage |
100 - 240 V |
| Power supply input frequency |
50/60 Hz |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating altitude |
0 - 3048 m |
| Non-operating altitude |
0 - 12192 m |
| Weight & dimensions |
| Width |
179 mm |
| Depth |
182.9 mm |
| Height |
36.5 mm |
| Weight |
2.65 kg |
| Package width |
313 mm |
| Package depth |
242 mm |
| Package height |
327 mm |
| Package weight |
4.9 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer |
Intel |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Antenna type |
2x2 |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| Operating system/software |
| Operating system installed |
Windows 11 IoT Enterprise |
| Operating system architecture |
64-bit |
| Operating system language |
English |
| Software |
| Operating system installed |
Windows 11 IoT Enterprise |
| Operating system architecture |
64-bit |
| Operating system language |
English |
| Storage |
| Total storage capacity |
256 GB |
| Optical drive type |
No |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
256 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
256 GB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Graphics |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel UHD Graphics 730 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel® UHD Graphics |
| Design |
| Chassis type |
Mini PC |
| Product colour |
Black |
| Colour name |
Black |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Performance |
| Product type |
Mini PC |
| Motherboard chipset |
Intel Q670 |
| Audio chip |
Realtek ALC256-VB |
| Audio system |
High Definition Audio |
| Password protection |
Yes |
| Password protection type |
BIOS, HDD, Power on, Supervisor |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Technical details |
| Box contents |
HDMI Ingest Dongle |
| Display |
| Display included |
Yes |
| Display diagonal |
25.6 cm (10.1") |
| Display resolution |
1280 x 800 pixels |
| Native aspect ratio |
16:10 |
| Display brightness |
340 cd/m² |
