Networking |
Maximum data transfer rate |
1000 Mbit/s |
Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
Ethernet LAN |
Yes |
Ethernet interface type |
Gigabit Ethernet |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Cabling technology |
10/100/1000BaseT(X) |
Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
Wake-on-LAN ready |
Yes |
Full duplex |
Yes |
Supported network protocols |
IPv4/IPv6 |
System requirements |
Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, |
Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
Weight & dimensions |
Width |
27 mm |
Depth |
16 mm |
Height |
95 mm |
Weight |
42 g |
Ports & interfaces |
Connectivity technology |
Wired |
Host interface |
USB |
Interface |
Ethernet |
Ethernet LAN (RJ-45) ports |
1 |
USB ports quantity |
3 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity |
3 |
USB version |
3.2 Gen 1 (3.1 Gen 1) |
Operational conditions |
Operating temperature (T-T) |
0 - 40 °C |
Storage temperature (T-T) |
-5 - 80 °C |
Operating relative humidity (H-H) |
0 - 85% |
Storage relative humidity (H-H) |
0 - 85% |
Power |
Input current |
0.9 A |
Output voltage |
5 V |
USB powered |
Yes |
Other features |
Flow control support |
Yes |
Design |
Internal |
No |
Product colour |
Silver, White |
Hot-swap |
Yes |
Plug and Play |
Yes |
Country of origin |
China |
Certification |
CE |
Logistics data |
Master (outer) case width |
33.5 mm |
Master (outer) case length |
20 mm |
Master (outer) case height |
44 mm |
Master (outer) case gross weight |
5.5 kg |
Products per master (outer) case |
80 pc(s) |
Packaging data |
Package type |
Box |
Package width |
90 mm |
Package depth |
21 mm |
Package height |
165 mm |
Package weight |
60 g |
Packaging content |
Quick installation guide |
Yes |
Sustainability |
Sustainability certificates |
RoHS |
