Revitalize Productive Collaboration
Samsung's QBH-TR / QBN-W e-boards offer a versatile, all-in-one arena for improved collaboration. Enhanced touch technology, the intuitive MagicIWB S5 solution and UHD picture quality come together to boost productivity and collaboration by facilitating engaging, efficient interaction.
Specs
| Weight & dimensions |
| Width |
1741.5 mm |
| Height |
1012.1 mm |
| Depth |
81.2 mm |
| Weight |
57.4 kg |
| Technical details |
| Colour gamut |
72% |
| Horizontal scan range |
30 - 81 kHz |
| Vertical scan range |
48 - 75 Hz |
| Power |
| Power consumption (typical) |
220 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Ports & interfaces |
| Wi-Fi |
Y |
| Ethernet LAN |
Y |
| HDMI ports quantity |
3 |
| Ethernet LAN (RJ-45) ports |
2 |
| Audio |
| Built-in speaker(s) |
Y |
| Number of built-in speakers |
2 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Packaging data |
| Package width |
1905 mm |
| Package depth |
307 mm |
| Package height |
1175 mm |
| Package weight |
69.5 kg |
| Ergonomics |
| VESA mounting |
Y |
| Panel mounting interface |
400 x 400 mm |
| Projector |
| Built-in projector |
N |
| Weight & dimensions |
| Width |
1741.5 mm |
| Depth |
81.2 mm |
| Height |
1012.1 mm |
| Weight |
57.4 kg |
| Display |
| Display diagonal |
190.5 cm (75") |
| Display type |
LED |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
250 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
N |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
6000:1 |
| Dynamic contrast ratio marketing name |
Mega Contrast |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.42975 x 0.42975 mm |
| Horizontal scan range |
30 - 81 kHz |
| Vertical scan range |
48 - 75 Hz |
| Colour gamut |
72% |
| Packaging data |
| Package width |
1905 mm |
| Package depth |
307 mm |
| Package height |
1175 mm |
| Package weight |
69.5 kg |
| Audio |
| Built-in speaker(s) |
Y |
| Number of built-in speakers |
2 |
| RMS rated power |
10 W |
| Power |
| Power consumption (typical) |
220 W |
| Power consumption (standby) |
0.5 W |
| Energy efficiency class |
B |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| DVI port |
Y |
| USB port |
Y |
| Ethernet LAN |
Y |
| Wi-Fi |
Y |
| DVI-I ports quantity |
1 |
| USB ports quantity |
3 |
| USB version |
2.0 |
| Ethernet LAN (RJ-45) ports |
2 |
| RS-232C |
Y |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Design |
| Design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Y |
| Panel mounting interface |
400 x 400 mm |
| Bezel width (bottom) |
4.89 cm |
| Bezel width (side) |
3.3 cm |
| Bezel width (top) |
3.3 cm |
| Performance |
| Purpose |
Universal |
| Features |
| Display diagonal |
190.5 cm (75") |
| Touchscreen |
N |
| Display brightness |
250 cd/m² |
| Display resolution |
3840 x 2160 pixels |
| HD type |
4K Ultra HD |
| Contrast ratio (typical) |
6000:1 |
| Response time |
8 ms |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.42975 x 0.42975 mm |
| Product colour |
Black |
Features
Samsung LH75QBNWLGC. Display diagonal: 190.5 cm (75"), Display brightness: 250 cd/m², Display resolution: 3840 x 2160 pixels. Panel mounting interface: 400 x 400 mm. Power consumption (typical): 220 W, Power consumption (standby): 0.5 W, AC input voltage: 100 - 240 V. Width: 1741.5 mm, Height: 1012.1 mm, Depth: 81.2 mm. Package width: 1905 mm, Package depth: 307 mm, Package height: 1175 mm
Product Description
Revitalize Productive Collaboration
Samsung's QBH-TR / QBN-W e-boards offer a versatile, all-in-one arena for improved collaboration. Enhanced touch technology, the intuitive MagicIWB S5 solution and UHD picture quality come together to boost productivity and collaboration by facilitating engaging, efficient interaction.
