Stock Status: 1x unit in stock
Plug and Play
Simple plug and play installation with auto-MDI/MDIX crossover on all ports
Multi-Port FE Connectivity
Four Fast Ethernet LAN ports to connect multiple devices for general M2M applications.
SMS Event Management
Facilitate remote management via SMS, minimizing staff exposure to hazardous environments.
Industrial-Grade Durability
Corrosion-resistant zinc-plated steel casing and robust design ensure reliable operation in harsh environments.
Secure VPN Protection
Protect sensitive data transmission via secure VPN tunnels to prevent unauthorized network access.
Centralized Management
Conveniently manage devices from anywhere via the D-ECS management platform.
Optimize Smart Parking with 4G LTE Connectivity
The DWM-314-T 4G Multi-Connect Modem enhances smart parking solutions with uninterrupted 4G LTE connectivity, facilitating real-time data transmission to alleviate traffic congestion and increase parking efficiency. This modem features a built-in 4-port Gigabit switch, minimizing the extra power supply wires and the need for additional equipment, reducing extra switch cost and installation complexity. Secure VPN technology protects vehicle information and parking fee transactions, ensuring robust security for both drivers and parking management.
Plug & Play for Easy Installation
Simply insert a Nano-SIM card (4FF) and power up; the DWM-314-T instantly connects your M2M devices to the robust 4G LTE cellular network. This modem’s rugged, compact design is perfect for any setting, including harsh environments, offering flexible wall and DIN-rail mounting options. Designed for effortless, real-time remote access, it provides reliable long-distance connectivity ideal for various applications.
Robust Build Quality
The industrial-grade casing provides reliable high-speed connectivity in extreme conditions. The corrosion-resistant zinc-plated steel case with wide operating temperature range and humidity tolerance mean that the DWM-314-T is ready for the most demanding M2M applications in virtually any environment.
Specs
| Ethernet LAN features |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Ethernet LAN data rates |
10,100 Mbit/s |
| DHCP server |
Yes |
| Security |
| Security algorithms |
SSH |
| Network address translation (NAT) |
Yes |
| Firewall |
Yes |
| Port forwarding |
Yes |
| Weight & dimensions |
| Width |
115 mm |
| Depth |
99 mm |
| Height |
31 mm |
| Operational conditions |
| Operating temperature (T-T) |
-30 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Operating relative humidity (H-H) |
10 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Power |
| Power source type |
DC |
| Input voltage |
9 - 36 V |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
4 |
| Performance |
| Web-based management |
Yes |
| Antenna type |
External |
| Antenna connector type |
SMA |
| Antennas quantity |
2 |
| Wireless LAN features |
| Wi-Fi |
No |
| Design |
| Device type |
Cellular network router |
| Product colour |
Black |
| Mounting |
DIN-rail |
| Reset button |
Yes |
| LED indicators |
Yes |
| Mobile network |
| Data network |
4G |
| 4G standard |
LTE |
| Number of SIM cards |
1 |
| Certification |
| Certification |
CE; UKCA |
Features
D-Link 4G LTE M2M VPN Router. Device type: Cellular network router, Product colour: Black, Mounting: DIN-rail. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s. Data network: 4G, 4G standard: LTE. Security algorithms: SSH. Certification: CE; UKCA
Product Description
Plug and Play
Simple plug and play installation with auto-MDI/MDIX crossover on all ports
Multi-Port FE Connectivity
Four Fast Ethernet LAN ports to connect multiple devices for general M2M applications.
SMS Event Management
Facilitate remote management via SMS, minimizing staff exposure to hazardous environments.
Industrial-Grade Durability
Corrosion-resistant zinc-plated steel casing and robust design ensure reliable operation in harsh environments.
Secure VPN Protection
Protect sensitive data transmission via secure VPN tunnels to prevent unauthorized network access.
Centralized Management
Conveniently manage devices from anywhere via the D-ECS management platform.
Optimize Smart Parking with 4G LTE Connectivity
The DWM-314-T 4G Multi-Connect Modem enhances smart parking solutions with uninterrupted 4G LTE connectivity, facilitating real-time data transmission to alleviate traffic congestion and increase parking efficiency. This modem features a built-in 4-port Gigabit switch, minimizing the extra power supply wires and the need for additional equipment, reducing extra switch cost and installation complexity. Secure VPN technology protects vehicle information and parking fee transactions, ensuring robust security for both drivers and parking management.
Plug & Play for Easy Installation
Simply insert a Nano-SIM card (4FF) and power up; the DWM-314-T instantly connects your M2M devices to the robust 4G LTE cellular network. This modem’s rugged, compact design is perfect for any setting, including harsh environments, offering flexible wall and DIN-rail mounting options. Designed for effortless, real-time remote access, it provides reliable long-distance connectivity ideal for various applications.
Robust Build Quality
The industrial-grade casing provides reliable high-speed connectivity in extreme conditions. The corrosion-resistant zinc-plated steel case with wide operating temperature range and humidity tolerance mean that the DWM-314-T is ready for the most demanding M2M applications in virtually any environment.
