| Networking |
| Maximum data transfer rate |
1000 Mbit/s |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Ethernet LAN |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wake-on-LAN ready |
Yes |
| Full duplex |
Yes |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Weight & dimensions |
| Width |
26.5 mm |
| Depth |
205 mm |
| Height |
15 mm |
| Weight |
28 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB Type-C |
| Interface |
Ethernet |
| Ethernet LAN (RJ-45) ports |
1 |
| USB version |
2.0/3.2 Gen 2 (3.1 Gen 2) |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
5 - 90% |
| Power |
| Input current |
0.5 A |
| Output voltage |
5 V |
| Power consumption |
176 mA |
| USB powered |
Yes |
| Design |
| Internal |
No |
| Product colour |
White |
| Plug and Play |
Yes |
| LED indicators |
Link, Speed |
| Certification |
CE, FCC |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Shipping (inner) case net weight |
1.4 kg |
| Shipping (inner) case length |
33.5 cm |
| Shipping (inner) case height |
30.2 cm |
| Shipping (inner) case width |
28.6 cm |
| Products per shipping (inner) case |
40 pc(s) |
| Pallet gross weight (air) |
166.8 kg |
| Master (outer) cases per pallet (air) |
27 pc(s) |
| Products per pallet (air) |
1080 pc(s) |
| Pallet height (air) |
120 cm |
| Pallet gross weight (sea) |
298.8 kg |
| Master (outer) cases per pallet (sea) |
51 pc(s) |
| Products per pallet (sea) |
2040 pc(s) |
| Pallet height (sea) |
192 cm |
| Pallet gross width |
110 cm |
| Pallet gross length |
120 cm |
| Packaging data |
| Package width |
138 mm |
| Package depth |
138 mm |
| Package height |
30 mm |
| Package weight |
99 g |
