| Weight & dimensions |
| Width |
304.8 mm |
| Depth |
243.8 mm |
| Memory |
| Supported memory types |
DDR5-SDRAM |
| Number of memory slots |
4 |
| Maximum internal memory |
128 GB |
| ECC сompatibility |
Non-ECC |
| Supported memory clock speeds |
4800,5000,5200,5400,5600,5800,6000,6200,6400,6600 MHz |
| Processor |
| Processor manufacturer |
AMD |
| Processor socket |
Socket AM5 |
| Compatible processor series |
AMD Ryzen 7000 Series |
| Supported processor sockets |
Socket AM5 |
| Back panel I/O ports |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| VGA (D-Sub) ports quantity |
0 |
| HDMI ports quantity |
1 |
| DVI-D ports quantity |
0 |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| HDMI version |
2.1 |
| Headphone outputs |
1 |
| Microphone in |
Yes |
| S/PDIF out port |
Yes |
| Internal I/O |
| USB 2.0 connectors |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
0 |
| Number of SATA III connectors |
6 |
| Number of SATA II connectors |
0 |
| Number of SATA connectors |
0 |
| Front panel audio connector |
Yes |
| Front panel connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| CPU fan connector |
Yes |
| Chassis intrusion connector |
Yes |
| Networking |
| Wi-Fi |
Yes |
| Ethernet LAN |
Yes |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| LAN controller |
Realtek RTL8125B |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
| Bluetooth |
Yes |
| Bluetooth version |
5.2 |
| Expansion slots |
| PCI Express x16 (Gen 3.x) slots |
1 |
| Number of M.2 (M) slots |
3 |
| Features |
| Component for |
PC |
| Motherboard form factor |
ATX |
| Motherboard chipset family |
AMD |
| Motherboard chipset |
AMD B650 |
| Audio output channels |
7.1 channels |
| Audio chip |
Realtek ALC4080 |
| Product colour |
Black |
| PC health monitoring |
Fan |
| Windows operating systems supported |
Windows 11 x64 |
| Storage controllers |
| Supported storage drive interfaces |
M.2, SATA |
| RAID support |
Yes |
| RAID levels |
0, 1, 10 |
