Stock Status: 1x unit in stock
Improve speed, accuracy and productivity._x000D_
Manhattan CCD Contact Barcode Scanners deliver high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The CCD (charged-coupled device) scan engine features no moving parts for years of reliable service reading popular barcodes, including UPC, EAN, ASCII and GS1 DataBar. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application, where it appears as if it were manually typed or directly keyed into the computer. Its USB cable interface integrates with most PCs without an external power supply. With a scan rate of 100 scans per second and an accurate read range of up to 60 mm (2.4 in.), this model offers a practical daily scanning solution for point-of-sale, shipping, warehousing, office and industrial applications to minimize manual data entry, speed transactions and reduce errors.
Specs
| Weight & dimensions |
| Weight |
180 g |
| Width |
80 mm |
| Depth |
180 mm |
| Height |
63.5 mm |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
20 - 95% |
| Power |
| Input voltage |
5 V |
| Power consumption |
80 mA |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Standard interfaces |
Keyboard wedge, RS-232, USB |
| Cable length |
1.524 m |
| Scanning |
| Type |
Handheld bar code reader |
| Scanner type |
1D |
| Sensor type |
CCD |
| Linear (1D) barcodes supported |
Codabar, Code 11, Code 128, Code 39, Code 93, JAN, MSI, U.P.C. |
| 2D (matrix & stacked) barcodes supported |
Not supported |
| Working distance |
6 cm |
| Read rate (max) |
100 reads/s |
| Light levels (direct sunlight) |
0 - 5000 lx |
| Wavelength |
632 nm |
| Maximum scan width |
6 cm |
| Scanner resolution |
0.127 mm |
| Performance |
| Product colour |
Black |
| Housing material |
Acrylonitrile butadiene styrene (ABS) |
| Certification |
• FCC
• CE
• RoHS |
| Logistics data |
| Harmonized System (HS) code |
84716070 |
| Technical details |
| Compliance certificates |
RoHS |
Features
Manhattan Contact CCD Handheld Barcode Scanner, USB, 60mm Scan Width, Cable 152cm, Max Ambient Light 5,000 lux (sunlight), Black, Three Year Warranty, Box. Type: Handheld bar code reader, Scanner type: 1D, Sensor type: CCD. Connectivity technology: Wired, Standard interfaces: Keyboard wedge, RS-232, USB, Cable length: 1.524 m. Product colour: Black, Housing material: Acrylonitrile butadiene styrene (ABS), Certification: • FCC • CE • RoHS. Input voltage: 5 V, Power consumption: 80 mA. Weight: 180 g, Width: 80 mm, Depth: 180 mm
Product Description
Improve speed, accuracy and productivity._x000D_
Manhattan CCD Contact Barcode Scanners deliver high-quality scanning for a wide range of data collection functions to help improve routine transactions, automate paper-based processes and increase productivity. The CCD (charged-coupled device) scan engine features no moving parts for years of reliable service reading popular barcodes, including UPC, EAN, ASCII and GS1 DataBar. Easy to implement and simple to use, a built-in keyboard wedge decoder sends scanned data to an active application, where it appears as if it were manually typed or directly keyed into the computer. Its USB cable interface integrates with most PCs without an external power supply. With a scan rate of 100 scans per second and an accurate read range of up to 60 mm (2.4 in.), this model offers a practical daily scanning solution for point-of-sale, shipping, warehousing, office and industrial applications to minimize manual data entry, speed transactions and reduce errors.
