Stock Status: 1x unit in stock
STEP UP TO BRILLIANT PC GRAPHICS
Accelerate your entire PC experience with the fast, powerful NVIDIA® GeForce® GT 1030 graphics card. Gaming. HD video and picture editing. The GT 1030's award-winning NVIDIA Pascal™ architecture, powerful graphics engine, and state-of-the-art technologies give you the performance upgrade you need to drive today’s most demanding PC applications.
THE LATEST GAMING TECHNOLOGIES
Pascal is built to meet the demands of next generation displays. It features NVIDIA GameWorks™ technologies for extremely smooth gameplay and cinematic experiences.
PERFORMANCE
Pascal-powered graphics cards give you superior performance and power efficiency, built using ultra-fast FinFET and supporting DirectX™ 12 features to deliver the fastest, smoothest, most power-efficient gaming experiences.
GEFORCE EXPERIENCE
The easiest way to optimize your games and keep your drivers up to date, the GeForce Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you'll be able to update the driver directly, without leaving your desktop.
LOW PROFILE DESIGN
Low profile design saves more spaces and can build slim or smaller system easier.
MILITARY CLASS 4 COMPONENTS
One of the deciding factors in performance is the quality of the components used. That is why MSI only uses MIL-STD-810G certified components for graphics cards. These components have proven durable enough to withstand the torturous circumstances of extreme gaming and overclocking for extended usage.
AFTERBURNER
MSI Afterburner is the world’s most recognized and widely used graphics card overclocking utility which gives you full control of your graphics cards. It also provides an incredibly detailed overview of your hardware and comes with some additional features such as customizing fan profiles, benchmarking and video recording.
Specs
| System requirements |
| Windows operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Weight & dimensions |
| Weight |
304 g |
| Length |
150 mm |
| Depth |
38 mm |
| Height |
69 mm |
| Processor |
| Graphics processor family |
NVIDIA |
| Graphics processor |
GeForce GT 1030 |
| CUDA |
Yes |
| Processor frequency |
1189 MHz |
| Parallel processing technology support |
Not supported |
| CUDA cores |
384 |
| Processor boost clock speed |
1430 MHz |
| Maximum displays per videocard |
2 |
| FireStream |
No |
| Memory |
| Discrete graphics card memory |
2 GB |
| Graphics card memory type |
GDDR4 |
| Memory bus |
64 bit |
| Memory clock speed |
2100 MHz |
| Ports & interfaces |
| Interface type |
PCI Express x16 3.0 |
| HDMI ports quantity |
1 |
| DVI-D ports quantity |
0 |
| DVI-I ports quantity |
0 |
| DisplayPorts quantity |
1 |
| HDMI version |
2.0b |
| VGA (D-Sub) ports quantity |
0 |
| DisplayPort version |
1.4a |
| USB Type-C ports quantity |
0 |
| Power |
| Minimum system power supply |
300 W |
| Power consumption (typical) |
20 W |
| Packaging data |
| Package weight |
544 g |
| Package type |
Box |
| Performance |
| TV tuner integrated |
No |
| DirectX version |
12.0 |
| OpenGL version |
4.5 |
| Dual Link DVI |
No |
| PhysX |
Yes |
| HDCP |
Yes |
| Full HD |
Yes |
| Overclocked (OC) edition |
Yes |
| Design |
| Cooling type |
Passive |
| Number of fans |
0 fan(s) |
| Form factor |
Half-Height/Half-Length (HH/HL) |
| Bracket height |
Low-Profile (LP) |
| Number of slots |
1 |
| Illumination |
No |
| Product colour |
Black |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
Features
MSI GeForce GT 1030 2GHD4 LP OC. Graphics processor family: NVIDIA, Graphics processor: GeForce GT 1030, Processor frequency: 1189 MHz. Discrete graphics card memory: 2 GB, Graphics card memory type: GDDR4, Memory bus: 64 bit, Memory clock speed: 2100 MHz. DirectX version: 12.0, OpenGL version: 4.5. Interface type: PCI Express x16 3.0. Cooling type: Passive, Number of fans: 0 fan(s)
Product Description
STEP UP TO BRILLIANT PC GRAPHICS
Accelerate your entire PC experience with the fast, powerful NVIDIA® GeForce® GT 1030 graphics card. Gaming. HD video and picture editing. The GT 1030's award-winning NVIDIA Pascal™ architecture, powerful graphics engine, and state-of-the-art technologies give you the performance upgrade you need to drive today’s most demanding PC applications.
THE LATEST GAMING TECHNOLOGIES
Pascal is built to meet the demands of next generation displays. It features NVIDIA GameWorks™ technologies for extremely smooth gameplay and cinematic experiences.
PERFORMANCE
Pascal-powered graphics cards give you superior performance and power efficiency, built using ultra-fast FinFET and supporting DirectX™ 12 features to deliver the fastest, smoothest, most power-efficient gaming experiences.
GEFORCE EXPERIENCE
The easiest way to optimize your games and keep your drivers up to date, the GeForce Experience application automatically notifies you of new driver releases from NVIDIA. With a single click, you'll be able to update the driver directly, without leaving your desktop.
LOW PROFILE DESIGN
Low profile design saves more spaces and can build slim or smaller system easier.
MILITARY CLASS 4 COMPONENTS
One of the deciding factors in performance is the quality of the components used. That is why MSI only uses MIL-STD-810G certified components for graphics cards. These components have proven durable enough to withstand the torturous circumstances of extreme gaming and overclocking for extended usage.
AFTERBURNER
MSI Afterburner is the world’s most recognized and widely used graphics card overclocking utility which gives you full control of your graphics cards. It also provides an incredibly detailed overview of your hardware and comes with some additional features such as customizing fan profiles, benchmarking and video recording.
