Stock Status: 1x unit in stock
Enjoy the most natural interactive digital experience
Modern meeting spaces drive the demand for advanced touch technology with innovative design. To support interactive sessions, the NEC InGlassTM Touch Board along with the responsive passive pen brings superior paper-like writing with minimal latency to a digital canvas. With its slim bezel design, the technology seamlessly integrates into modern interior styling.
High brightness levels ensure excellent readability and image reproduction even in today’s typically bright meeting spaces where maintaining a motivational environment is paramount. The anti-glare coating minimizes disturbing reflections and helps to eliminate niggling fingerprints on the touch surface.
Specs
| Weight & dimensions |
| Display width |
1972 mm |
| Display depth |
91.5 mm |
| Display height |
1142 mm |
| Display weight |
76 kg |
| Display |
| Display diagonal |
2.18 m (86") |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
Yes |
| Panel type |
IPS |
| LED backlight |
Yes |
| LED backlighting type |
Direct-LED |
| Touchscreen technology |
InGlass |
| Number of simultaneous touchpoints |
20 |
| Multi-touch |
Yes |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
8000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.073 billion colours |
| Display diagonal (metric) |
217.4 cm |
| Horizontal scan range |
15 - 135 kHz |
| Vertical scan range |
23 - 76 Hz |
| Colour depth |
10 bit |
| Native refresh rate |
60 Hz |
| Haze rate |
28% |
| Surface hardness |
7H |
| Touch response time |
15 ms |
| Colour gamut |
68% |
| Packaging data |
| Package width |
2090 mm |
| Package depth |
225 mm |
| Package height |
1225 mm |
| Package weight |
94.1 kg |
| Audio |
| Built-in speaker(s) |
No |
| Power |
| Power consumption (typical) |
320 W |
| Power consumption (standby) |
0.5 W |
| Energy consumption (SDR) per 1000 hours |
193 kWh |
| AC input voltage |
100-240 V |
| AC input frequency |
50-60 Hz |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| DisplayPorts quantity |
3 |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| HDMI input ports quantity |
2 |
| HDMI output ports quantity |
1 |
| DisplayPorts in |
2 |
| DisplayPorts out |
1 |
| USB ports quantity |
3 |
| USB version |
2.0 |
| USB connector type |
USB Type-A, USB Type-B |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Number of speaker outputs |
1 |
| RS-232 interface |
Yes |
| SDM module slot |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 35 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
10 - 80% |
| Design |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Yes |
| Orientation |
Horizontal/Vertical |
| Panel mounting interface |
600 x 400 mm |
| Bezel width (bottom) |
2.25 cm |
| Bezel width (side) |
2.25 cm |
| Bezel width (top) |
2.25 cm |
| Anti-glare screen |
Yes |
| Positioning accuracy |
1 mm |
| Performance |
| Purpose |
Corporate |
| Picture-in-Picture |
Yes |
| Operating hours (hours/days) |
24/7 |
| Pen type |
Passive pen |
| International Protection (IP) code |
IP5X, IP2X |
| Packaging content |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Stylus pen |
Yes |
| Number of stylus pens |
2 |
| Cables included |
AC, HDMI, USB |
Features
NEC MultiSync M861 IGB. Product design: Digital signage flat panel. Display diagonal: 2.18 m (86"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD, Touchscreen. Operating hours (hours/days): 24/7. Product colour: Black
Product Description
Enjoy the most natural interactive digital experience
Modern meeting spaces drive the demand for advanced touch technology with innovative design. To support interactive sessions, the NEC InGlassTM Touch Board along with the responsive passive pen brings superior paper-like writing with minimal latency to a digital canvas. With its slim bezel design, the technology seamlessly integrates into modern interior styling.
High brightness levels ensure excellent readability and image reproduction even in today’s typically bright meeting spaces where maintaining a motivational environment is paramount. The anti-glare coating minimizes disturbing reflections and helps to eliminate niggling fingerprints on the touch surface.
