| Processor |
| Processor family |
Intel Core Ultra 7 |
| Processor manufacturer |
Intel |
| Processor model |
258V |
| Processor frequency |
2.2 GHz |
| Processor cores |
8 |
| Processor threads |
4 |
| Processor boost frequency |
4.8 GHz |
| Performance cores |
4 |
| Efficient cores |
0 |
| Low Power Efficient-cores |
4 |
| Performance-core Max Turbo Frequency |
4.8 GHz |
| Low Power Efficient-core Max Turbo Frequency |
3.7 GHz |
| Performance-core base frequency |
2.2 GHz |
| Low Power Efficient-core Base Frequency |
2.2 MHz |
| Processor cache |
12 MB |
| Processor cache type |
Smart Cache |
| Number of processors installed |
1 |
| Processor base power |
17 W |
| Maximum turbo power |
37 W |
| Memory |
| Internal memory |
32 GB |
| Maximum internal memory |
96 GB |
| Internal memory type |
LPDDR5x-SDRAM |
| Memory layout (slots x size) |
1 x 32 GB |
| Memory slots |
1x SO-DIMM |
| Memory clock speed |
7467 MHz |
| ECC |
No |
| Non-ECC |
Yes |
| Memory channels |
Dual-channel |
| Buffered memory type |
Clocked unregistered (unbuffered) |
| Memory data transfer rate |
7467 MT/s |
| Ports & interfaces |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 2x2 Type-C ports quantity |
0 |
| USB4 Gen 2x2 ports quantity |
0 |
| USB4 Gen 3x2 ports quantity |
0 |
| PowerShare |
Yes |
| Number of USB ports with PowerShare support |
1 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Intel® Thunderbolt 4 |
Yes |
| Thunderbolt 4 ports quantity |
2 |
| Intel® Thunderbolt 5 |
No |
| Thunderbolt 5 ports quantity |
0 |
| VGA (D-Sub) ports quantity |
0 |
| DVI port |
No |
| HDMI version |
2.1 |
| DisplayPorts quantity |
0 |
| Mini DisplayPorts quantity |
0 |
| PS/2 ports quantity |
0 |
| Firewire (IEEE 1394) ports |
0 |
| eSATA ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Yes |
| Headphone outputs |
1 |
| Line-out |
No |
| Line-in |
No |
| Combo headphone/mic port |
Yes |
| S/PDIF out port |
No |
| DC-in jack |
No |
| Serial ports quantity |
0 |
| Parallel ports quantity |
0 |
| Number of rear USB ports |
2 |
| Number of front USB ports |
2 |
| Number of front audio ports |
1 |
| Number of rear audio ports |
0 |
| Fiber NIC port (Flex I/O) |
No |
| Number of side USB ports |
0 |
| Total number of SATA connectors |
0 |
| Number of SATA III connectors |
0 |
| Power |
| Power supply |
120 W |
| Power supply input voltage |
100 - 240 V |
| Power supply input frequency |
50 - 60 Hz |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
| Width |
135.6 mm |
| Depth |
132.5 mm |
| Height |
50.1 mm |
| Weight |
630 g |
| Package width |
205 mm |
| Package depth |
220 mm |
| Package height |
94 mm |
| Package weight |
1.38 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
2500 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel I226-V |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer |
Intel |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Antenna type |
2x2 |
| Bluetooth |
Yes |
| Bluetooth version |
5.3 |
| Bluetooth Low Energy (BLE) |
Yes |
| Wake-on-LAN ready |
Yes |
| Miracast |
Yes |
| Certificates |
| Waste Electrical and Electronic Equipment (WEEE) compliance |
Yes |
| Compliance certificates |
CB, Federal Communications Commission (FCC) |
| Operating system/software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
English |
| Windows 11 free upgrade |
No |
| Apple Intelligence |
No |
| Drivers included |
Yes |
| Software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
English |
| Windows 11 free upgrade |
No |
| Apple Intelligence |
No |
| Drivers included |
Yes |
| Storage |
| Total storage capacity |
1 TB |
| Optical drive type |
No |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Number of storage drives supported |
1 |
| Total HDDs capacity |
0 GB |
| Number of HDDs installed |
0 |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| SSD memory type |
TLC |
| SSD interface |
PCI Express |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Card reader integrated |
No |
| Intel® Optane™ Memory module installed |
No |
| Expansion slots |
| PCI Express x1 slots |
1 |
| PCI Express x1 (Gen 1.x) slots |
0 |
| PCI Express x1 (Gen 2.x) slots |
0 |
| PCI Express x1 (Gen 3.x) slots |
1 |
| PCI Express x1 (Gen 4.x) slots |
0 |
| PCI Express x4 slots |
0 |
| PCI Express x4 (Gen 1.x) slots |
0 |
| PCI Express x4 (Gen 2.x) slots |
0 |
| PCI Express x4 (Gen 3.x) slots |
0 |
| PCI Express x4 (Gen 4.x) slots |
0 |
| PCI Express x8 slots |
0 |
| PCI Express x8 (Gen 1.x) slots |
0 |
| PCI Express x8 (Gen 2.x) slots |
0 |
| PCI Express x8 (Gen 3.x) slots |
0 |
| PCI Express x8 (Gen 4.x) slots |
0 |
| PCI Express x16 slots |
1 |
| PCI Express x16 (Gen 1.x) slots |
0 |
| PCI Express x16 (Gen 2.x) slots |
0 |
| PCI Express x16 (Gen 3.x) slots |
1 |
| PCI Express x16 (Gen 4.x) slots |
0 |
| PCI Express x16 (Gen 5.x) slots |
0 |
| Mini PCI Express slots |
0 |
| PCI slots |
0 |
| Other features |
| TV tuner integrated |
No |
| Built-in microphone |
No |
| Locale |
English |
| Warranty period |
3 year(s) |
| Graphics |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| On-board graphics card model |
Intel Arc Graphics |
| Number of discrete graphics cards |
0 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel Arc Graphics |
| On-board graphics card cores |
8 |
| On-board graphics card 6K support |
Yes |
| On-board graphics card 8K support |
Yes |
| Number of external displays supported |
4 |
| Graphics card Open GL support |
Yes |
| NVIDIA G-SYNC |
No |
| NVIDIA GameWorks VR |
No |
| CUDA |
No |
| AMD FreeSync |
Yes |
| Ray tracing acceleration |
Yes |
| Graphics card HDMI ports quantity |
0 |
| Graphics card DisplayPorts quantity |
0 |
| Graphics card DVI ports quantity |
0 |
| Graphics card DVI-I ports quantity |
0 |
| Graphics card DVI-D ports quantity |
0 |
| Graphics card VGA (D-Sub) ports quantity |
0 |
| Graphics card Mini DisplayPort ports quantity |
0 |
| Graphics card USB Type-C ports quantity |
0 |
| Packaging content |
| Mouse included |
No |
| Keyboard included |
No |
| Keyboard backlit |
No |
| Numeric keypad |
No |
| Cables included |
AC |
| VESA mount included |
Yes |
| Screws included |
Yes |
| Manual |
Yes |
| Processor special features |
| Video decode engine |
Yes |
| Video encode engine |
Yes |
| Design |
| Chassis type |
Mini PC |
| Product colour |
Black |
| Colour name |
black |
| Placement supported |
Horizontal/Vertical |
| VESA mounting |
Yes |
| Water cooling system |
No |
| Number of 3.5" bays |
1 |
| Number of 5.25" bays |
0 |
| Number of 2.5" bays |
1 |
| Cable lock slot |
No |
| Cable lock slot type |
Kensington |
| Copilot key |
No |
| Housing material |
Metal, Plastic |
| Viewing window |
No |
| RGB memory lighting |
No |
| Introduction year |
2025 |
| Introduction month |
June |
| Country of origin |
China |
| Refurbished |
No |
| Certified refurbished |
No |
| Performance |
| Product type |
Mini PC |
| Market positioning |
Business |
| Powered by |
MSI |
| Virtual Reality (VR) ready |
No |
| Motherboard form factor |
NUC |
| Audio chip |
Realtek ALC256 |
| Audio system |
High Definition Audio |
| Audio output channels |
2.0 channels |
| Built-in speaker(s) |
Yes |
| Number of speakers |
2 |
| Password protection |
Yes |
| Password protection type |
BIOS |
| Fingerprint reader |
No |
| BIOS type |
UEFI |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Technical details |
| Statement of conformance & platform certificate included |
Yes |
| Not classified as hazardous under GHS |
Yes |
| Neural processor unit (NPU) |
| Copilot+ PC |
No |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI datatype support on NPU |
FP16, Int8 |
| AI software frameworks supported by NPU |
ONNX RT, OpenVINO |
| Total processor performance up to |
34 TOPs |
| NPU performance up to |
10 TOPs |
| GPU performance up to |
15 TOPs |
| Display |
| Display included |
No |
