| Operational conditions |
| Operating relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Weight & dimensions |
| Width |
140 mm |
| Depth |
33 mm |
| Height |
175 mm |
| Weight |
452 g |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
4 |
| Power |
| Power over Ethernet (PoE) |
Yes |
| DC voltage range |
12 V |
| Input current |
1.5 A |
| Power consumption (max) |
17.3 W |
| Security |
| Security algorithms |
802.1x RADIUS, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal |
| Service Set Identifier (SSID) features |
Multiple SSIDs |
| Number of SSID supported |
16 |
| Access Control List (ACL) |
Yes |
| Other features |
| Wireless standard |
IEEE 802.11 a/b/g/n/ac/ax |
| Antenna |
| Antenna type |
Internal |
| Antenna gain level (max) |
4.7 dBi |
| Design |
| Placement |
Table |
| Product colour |
White |
| Reset button |
Yes |
| LED indicators |
Yes |
| Performance |
| Compatible operating systems |
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Features |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| 6 GHz |
No |
| Maximum data transfer rate |
2976 Mbit/s |
| Maximum data transfer rate (2.4 GHz) |
574 Mbit/s |
| Maximum data transfer rate (5 GHz) |
2402 Mbit/s |
| Ethernet LAN data rates |
1000 Mbit/s |
| Networking standards |
IEEE 802.3af, IEEE 802.3bt |
| Channel bandwidth |
160 MHz |
| MIMO |
Yes |
| MIMO type |
Multi User MIMO |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Load balancing |
Yes |
| Band steering |
Yes |
| Airtime Fairness (ATF) |
Yes |
| Quality of Service (QoS) support |
Yes |
| BeamForming |
Yes |
| Transmitting power (CE) |
20 - 29 dBm |
| Transmitting power (FCC) |
26 - 27 dBm |
| Management features |
| Web-based management |
Yes |
| Syslog |
Yes |
| Management platform |
Omada |
| Certification |
| Certification |
CE, FCC, RoHS, IC |
| Packaging content |
| Quantity per pack |
1 pc(s) |
