| Processor |
| Processor frequency |
3 GHz |
| Processor family |
Intel® Core™ i5 |
| Processor model |
i5-9500 |
| Processor cores |
6 |
| Number of processors installed |
1 |
| Processor boost frequency |
4.4 GHz |
| Processor cache |
9 MB |
| Thermal Design Power (TDP) |
65 W |
| Processor manufacturer |
Intel |
| Processor socket |
LGA 1151 (Socket H4) |
| Processor cache type |
Smart Cache |
| Processor threads |
6 |
| System bus rate |
8 GT/s |
| Processor lithography |
14 nm |
| Processor operating modes |
64-bit |
| Tjunction |
100 °C |
| PCI Express slots version |
3.0 |
| Maximum number of PCI Express lanes |
16 |
| PCI Express configurations |
1x8+2x4, 1x16, 2x8 |
| Maximum internal memory supported by processor |
128 GB |
| Memory types supported by processor |
DDR4-SDRAM |
| Memory clock speeds supported by processor |
2666 MHz |
| Memory bandwidth supported by processor (max) |
41.6 GB/s |
| Processor generation |
9th gen Intel® Core™ i5 |
| Memory |
| Internal memory |
8 GB |
| Internal memory type |
DDR4-SDRAM |
| Memory slots |
2x SO-DIMM |
| Memory clock speed |
2666 MHz |
| Non-ECC |
Yes |
| Memory channels |
Dual-channel |
| Optical drive |
| Optical drive type |
N |
| Optical drives quantity |
0 |
| Ports & interfaces |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| DVI port |
No |
| HDMI ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Yes |
| Headphone outputs |
1 |
| DisplayPorts quantity |
1 |
| Combo headphone/mic port |
Yes |
| On/off button |
Yes |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Thunderbolt 3 ports quantity |
0 |
| VGA (D-Sub) ports quantity |
0 |
| Power |
| Power supply |
135 W |
| Power supply input voltage |
100 - 240 V |
| Operational conditions |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
20 - 90% |
| Operating altitude |
-15.2 - 3048 m |
| Non-operating altitude |
-15.2 - 10668 m |
| Weight & dimensions |
| Width |
36.5 mm |
| Depth |
182.9 mm |
| Height |
179 mm |
| Weight |
1.4 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Wi-Fi standards |
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Antenna type |
2x2 |
| Bluetooth |
Yes |
| Bluetooth version |
4.2 |
| Certificates |
| RoHS compliance |
Y |
| EPEAT compliance |
Gold |
| Energy Star certified |
Y |
| Compliance certificates |
RoHS |
| Operating system/software |
| Operating system installed |
Windows 10 Pro |
| Operating system architecture |
64-bit |
| Software |
| Operating system installed |
Windows 10 Pro |
| Operating system architecture |
64-bit |
| Storage |
| Total storage capacity |
256 GB |
| Card reader integrated |
No |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
256 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
256 GB |
| Optical drive type |
No |
| Other features |
| Optical drives quantity |
0 |
| Graphics |
| On-board graphics adapter |
Y |
| On-board graphics adapter model |
Intel® UHD Graphics 630 |
| On-board graphics adapter family |
Intel® UHD Graphics |
| On-board graphics adapter base frequency |
350 MHz |
| On-board graphics adapter dynamic frequency (max) |
1100 MHz |
| Maximum on-board graphics adapter memory |
64 GB |
| Number of displays supported (on-board graphics) |
3 |
| On-board graphics adapter DirectX version |
12.0 |
| On-board graphics adapter OpenGL version |
4.5 |
| On-board graphics adapter ID |
0x3E92 |
| On-board graphics card |
Yes |
| On-board graphics card model |
Intel® UHD Graphics 630 |
| On-board graphics card family |
Intel® UHD Graphics |
| On-board graphics card base frequency |
350 MHz |
| On-board graphics card dynamic frequency (max) |
1100 MHz |
| Maximum on-board graphics card memory |
64 GB |
| On-board graphics card DirectX version |
12.0 |
| On-board graphics card OpenGL version |
4.5 |
| On-board graphics card ID |
0x3E92 |
| Packaging content |
| Mouse included |
Yes |
| Keyboard included |
Yes |
| Processor special features |
| Intel 64 |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Embedded options available |
No |
| Intel® InTru™ 3D Technology |
Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel Clear Video Technology |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel TSX-NI |
Yes |
| Idle States |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel Stable Image Platform Program (SIPP) |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
Yes |
| Intel® Secure Key |
Yes |
| Intel® OS Guard |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Execute Disable Bit |
Yes |
| Intel Software Guard Extensions (Intel SGX) |
Yes |
| Processor package size |
37.5 x 37.5 mm |
| Supported instruction sets |
AVX 2.0, SSE4.1, SSE4.2 |
| Scalability |
1S |
| CPU configuration (max) |
1 |
| Thermal solution specification |
PCG 2015C |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Processor ARK ID |
134895 |
| Intel® Turbo Boost Technology |
2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
No |
| Intel® Quick Sync Video Technology |
Yes |
| Intel® Identity Protection Technology (Intel® IPT) |
Yes |
| Design |
| Product colour |
Black |
| Chassis type |
Mini PC |
| Volume |
1 L |
| Placement supported |
Horizontal/Vertical |
| Water cooling system |
No |
| Intel® vPro™ Platform Eligibility |
Yes |
| Performance |
| Product type |
Workstation |
| Motherboard chipset |
Intel Q370 |
| Audio chip |
Realtek ALC233 |
| Audio system |
High Definition Audio |
| Password protection |
Yes |
| Password protection type |
Power on |
| Trusted Platform Module (TPM) |
Yes |
| Technical details |
| Sustainability certificates |
RoHS, EPEAT Gold, ENERGY STAR |
| Sustainability |
| Sustainability certificates |
EPEAT Gold, ENERGY STAR |
| Audio |
| Audio chip |
Realtek ALC233 |
| Audio system |
High Definition Audio |
