| Weight & dimensions |
| Display width |
1929 mm |
| Display depth |
69.5 mm |
| Display height |
1100 mm |
| Display weight |
49.1 kg |
| Base width |
1.55 cm |
| Display |
| Display diagonal |
2.17 m (85.6") |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
No |
| Panel type |
ADS |
| LED backlight |
Yes |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
500000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colours |
| Pixel pitch |
0.4935 x 0.4935 mm |
| Display diagonal (metric) |
217.4 cm |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Power |
| Power consumption (standby) |
0.5 W |
| Energy efficiency class (SDR) |
D |
| Energy consumption (SDR) per 1000 hours |
100 kWh |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency scale |
A to G |
| Ports & interfaces |
| HDMI ports quantity |
2 |
| DVI port |
Yes |
| USB port |
Yes |
| HDMI version |
2.0 |
| HDMI input ports quantity |
2 |
| DVI-I ports quantity |
1 |
| USB ports quantity |
2 |
| USB version |
2.0 |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Infrared data port |
Yes |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash) |
| OPS module slot |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
5 - 95% |
| Design |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Yes |
| Panel mounting interface |
600 x 400 mm |
| Performance |
| Purpose |
Commercial |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
12 |
| On Screen Display (OSD) languages |
Arabic, Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Polish, Russian, Turkish |
| Operating hours (hours/days) |
24/7 |
| Over the Air Updates (OTA) |
Yes |
| Open Pluggable Specification (OPS) |
Yes |
| Technical details |
| Warranty period |
3 year(s) |
| Compliance certificates |
CB, CE, Federal Communications Commission (FCC), RoHS, UL, VCCI |
| Computer system |
| Computer system |
Yes |
| Built-in processor |
Yes |
| Processor manufacturer |
ARM |
| Processor architecture |
ARM Cortex-A55 |
| Processor cores |
4 |
| Internal memory |
3 GB |
| On-board graphics card model |
Mali-G52 MC1 |
| Internal storage capacity |
16 GB |
| Operating system installed |
Android 10 |
| Video formats supported |
H.263, H.264, H.265, MPEG1, MPEG2, MPEG4, VP8, VP9 |
| Audio formats supported |
AAC, HE-AAC, MPEG-1, MPEG-2 |
| Image formats supported |
BMP, JPEG, PNG, WEBP |
| Features |
| Wall mountable |
Yes |
| Packaging content |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC, RS-232 |
| Network |
| Ethernet LAN |
Yes |
