| Ports & interfaces |
| Ethernet LAN |
Y |
| USB port |
Y |
| Ethernet interface type |
Gigabit Ethernet |
| USB connector |
USB Type-A |
| USB 2.0 ports quantity |
1 |
| RJ-45 ports quantity |
1 |
| Printing |
| Page description languages |
TIFF |
| Printing colours |
Blue, Gloss enhancer, Green, Light Cyan, Light grey, Light magenta, Magenta, Matte black, Photo black, Red, Yellow |
| Print head |
6 (magenta and yellow, light magenta and light cyan, photo black and light gray, matte black and red, gloss enhancer and gray, blue and green) |
| Print head nozzles |
12672 |
| Colour management |
HP Color Center, HP Vivera pigment inks, HP embedded spectrophotometer |
| Print speed (colour image, best quality, glossy paper) |
2.6 m2/hr
27.8 ft2/hr |
| Print speed (colour image, draft quality, coated paper) |
17 m2/hr
182.9 ft2/hr |
| Print speed (colour image, normal quality, coated paper) |
92.4 ft2/hr
8.6 m2/hr |
| Print speed (colour image, normal quality, glossy paper) |
47.6 ft2/hr
4.4 m2/hr |
| Power |
| Power requirements |
Input voltage (autoranging) 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz), 2 amps max |
| Power consumption (typical) |
200 W |
| Operational conditions |
| Operating temperature (T-T) |
59 - 95 °F |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-25 - 55 °C |
| Storage relative humidity (H-H) |
0 - 95% |
| Recommended operating temperature range (T-T) |
15 - 35 °C |
| Operating altitude (imperial) |
9,842 ft |
| System requirements |
| Browser supported |
Internet Explorer 5.0 and higher, Netscape 6.0.1 and higher, Safari for Mac OS 10.3 and higher, Mozilla 1.5 and higher |
| Compatible operating systems |
Microsoft Windows Vista (32/64-bit), XP Home, XP Professional, XP Professional x64, Server 2008 (32/64-bit), Windows Server 2003 (32/64 bit), Windows Terminal Services, Citrix MetaFrame, Mac OS X v 10.4, Mac OS X v 10.5 |
| Paper handling |
| Media types supported |
Photographic (satin, gloss, semi-gloss, matte), proofing (semi-gloss, high-gloss contract, semi-gloss contract, matte), fine art printing material (smooth, textured, watercolour, satin, aquarella, litho-realistic, canvas), self-adhesive (indoor, vinyl, po |
| Media thickness |
> 0.8 |
| Maximum roll length |
91.4 m |
| Maximum roll diameter |
13.6 cm |
| Maximum media width |
1118 mm |
| Roll top margin |
5 mm |
| Print margin cut-sheet |
5 x 17 x 5 x 5 |
| Print margin roll |
5 mm |
| Maximum print length |
91 m |
| Maximum length of sheet media |
1676.4 mm |
| Standard media sizes |
All standard sizes larger than A4 |
| Custom media sizes |
216 x 279 to 1118 x 1676 mm |
| Media weights by paper path |
133 lb |
| Recommended media weight |
500 g/m² |
| Media handling |
Sheet feed, roll feed, automatic cutter (cuts all media except canvas) |
| Media sizes supported (imperial) |
A, B, C, D, E |
| Media thickness (by paper path) |
Up to 31.5 mil |
| Non-printable area roll media (imperial) |
0.2 x 0.2 x 0.2 x 0.2 in (full bleed available on glossy/satin roll media) |
| Recommended media weight (imperial) |
133 lb |
| Weight & dimensions |
| Dimensions (WxDxH) |
1770 x 690 x 1047 mm |
| Weight |
86 kg |
| Product dimensions when open (LxWxD) |
177 cm (69.7") |
| Size (imperial) |
177 cm (69.7") |
| Maximum dimensions (W x D x H) |
1770 x 690 x 1047 mm |
| Pallet dimensions (W x D x H) |
1965 x 780 x 780 mm |
| Dimension note (imperial) |
printer with stand |
| Dimension note (metric) |
printer with stand |
| Pallet dimensions (W x D x H) (imperial) |
1963.4 x 779.8 x 779.8 mm (77.3 x 30.7 x 30.7") |
| Pallet weight (imperial) |
122.9 kg (271 lbs) |
| Weight (imperial) |
189 lb |
| Other features |
| Minimum system requirements for Macintosh |
Mac OS X v10.4, v10.5: PowerPC G3 or Intel Core Processor; 256 MB RAM; 1 GB available hard disk space |
| Line accuracy |
+/- 0.010 mm |
| Minimum system requirements |
Microsoft Windows XP Home, XP Professional: Intel Pentium 4, 1 GHz, 512 MB RAM, 2 GB available hard disk space
Mac OS X v10.4, v10.5: PowerPC G4, G5, or Intel Core Processor, 1 GB RAM, 2 GB available hard disk space |
| Embedded web server |
Y |
| Electromagnetic compatibility |
Compliance for Class B products: EU (EMC Directive), USA (FCC rules), Canada (DoC), Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI), Korea (MIC) and Taiwan (BSMI) |
| Printer management |
HP Web Jetadmin |
| Safety |
IEC 60950-1 compliant, EU LVD and EN 60950-1 compliant, certified by CSA for Canada and US, Argentina IRAM, Singapore PSB, Russia GOST, China CCIB, Taiwan BSMI |
| Maximum media length (imperial) |
66" |
| Print resolution (colour, normal quality) |
1200 x 1200 DPI |
| Minimum line width |
0.0558 mm |
| Compatible ink types, supplies |
HP Vivera pigment inks |
| Acoustic power emissions |
6.5 B(A) (active/printing), 4.4 B(A) (standby) |
| Print quality (colour, best quality) |
2400 DPI |
| Print quality (black, best quality) |
2400 x 1200 DPI |
| Print quality (black, draft quality) |
1200 DPI |
| Print quality (black, normal quality) |
1200 DPI |
| Driver updates |
Latest Windows printer drivers information available at http:// and more information on all printer drivers available at http:///country/us/en/support.html?pageDisplay=drivers |
| Ink drop |
4 pl (lc, lm, lg, pK, E, G), 6 pl (M, Y, mK, R, GN, B) |
| Control panel |
240 x 160 pixel greyscale graphical display with Asian fonts support, 4 direct-access buttons, 7 navigation buttons and 2 bicolour lights (Ready, Processing, Attention, Error) |
| Acoustic power emissions (standby) |
44 dB |
| JetDirect Compatible Products |
Y |
| Line width minimum |
0.0022 in |
| Maximum print length (imperial) |
300 ft; Operating system and application dependent |
| Media sizes standard (imperial rolls) |
Letter to E-size sheets, 11 to 44-in rolls |
| Non-printable area (imperial cut-sheet) |
0.2 x 0.67 x 0.2 x 0.2 in |
| Printing material waterfastness |
Water-resistant on a range of HP creative and speciaty papers |
| Roll maximum input |
1 |
| Acoustic pressure emissions (standby) |
29 dB(A) |
| Performance |
| Internal memory |
256 MB |
| Internal storage capacity |
80 GB |
| Storage media |
HDD |
| Built-in processor |
Mobile Intel Centrino |
| Processor frequency |
600 MHz |
| Certification |
SWOP, ISO, GRACOL, 3DAP |
| Logistics data |
| Products per pallet |
1 pc(s) |
| Pallet gross weight |
123 kg |
| Packaging data |
| Package weight |
123 kg |
| Package dimensions (WxDxH) |
1965 x 780 x 780 mm |
| Bundled software |
Printer drivers, HP Printer Utility including HP Color Center, HP Advanced Profiling Solution |
| Package dimensions (W x D x H) |
1963.4 x 779.8 x 779.8 mm (77.3 x 30.7 x 30.7") |
| Package weight (imperial) |
122.9 kg (271 lbs) |
| Sustainability |
| Sustainability certificates |
ENERGY STAR |
