| Weight & dimensions |
| Display width |
2565.2 mm |
| Display depth |
34.1 mm |
| Display height |
1467.6 mm |
| Display weight |
83.7 kg |
| Display |
| Display diagonal |
2.92 m (115") |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
1000 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
No |
| Panel type |
VA |
| Native aspect ratio |
16:9 |
| Response time |
6.5 ms |
| Contrast ratio (typical) |
5500:1 |
| Dynamic contrast ratio marketing name |
Mega Contrast |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.63 x 0.63 mm |
| Colour saturation |
93% |
| Horizontal scan range |
15 - 135 kHz |
| Vertical scan range |
24 - 120 Hz |
| Haze rate |
25% |
| Pixel frequency (max) |
1188 MHz |
| Packaging data |
| Package width |
2765 mm |
| Package depth |
250 mm |
| Package height |
1652 mm |
| Package weight |
133.6 kg |
| Power |
| Power consumption (typical) |
836 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| DVI port |
No |
| DisplayPorts quantity |
1 |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| HDMI version |
2.1 |
| DisplayPort version |
1.4 |
| USB ports quantity |
2 |
| USB connector type |
USB Type-A |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232C |
Yes |
| Remote (IR) input |
1 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 95% |
| Other features |
| Audio output |
1 |
| Bluetooth |
Yes |
| RS-232 input ports |
1 |
| RS-232 output ports |
1 |
| Design |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Yes |
| Orientation |
Horizontal/Vertical |
| Panel mounting interface |
1000 x 600 mm |
| Bezel type |
3 Bezel-less |
| Performance |
| Purpose |
Retail |
| Operating hours (hours/days) |
24/7 |
| Technical details |
| Compliance certificates |
Electromagnetic Compatibility (EMC) |
| Computer system |
| Internal storage capacity |
16 GB |
| Operating system installed |
Tizen |
| Operating system version |
8.0 |
