| Weight & dimensions |
| Display width |
1237.9 mm |
| Display depth |
28.5 mm |
| Display height |
708.8 mm |
| Display weight |
16.9 kg |
| Display |
| Display diagonal |
139.7 cm (55") |
| Display technology |
LED |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
700 cd/m² |
| HD type |
4K Ultra HD |
| LED backlight |
Yes |
| LED backlighting type |
Edge-LED |
| Native aspect ratio |
16:9 |
| Response time |
8 ms |
| Contrast ratio (typical) |
4000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
16.7 million colours |
| Active display area (W x H) |
1209.6 x 680.4 mm |
| Display diagonal (metric) |
138 cm |
| Frame width |
11.5 mm |
| Haze rate |
25% |
| Packaging data |
| Package width |
1403 mm |
| Package depth |
148 mm |
| Package height |
835 mm |
| Package volume |
21100 cm³ |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
10 W |
| Power |
| Power consumption (typical) |
109 W |
| Power consumption (standby) |
0.5 W |
| Energy efficiency class (SDR) |
G |
| Energy consumption (SDR) per 1000 hours |
109 kWh |
| Energy efficiency scale |
A to G |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| DisplayPorts quantity |
1 |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| HDMI version |
2.2 |
| USB ports quantity |
2 |
| USB version |
2.0 |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Design |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| VESA mounting |
Yes |
| Panel mounting interface |
200 x 200 mm |
| Performance |
| Operating hours (hours/days) |
24/7 |
| Computer system |
| Computer system |
Yes |
| Built-in processor |
Yes |
| Computer system type |
System on Chip (SoC) |
| Processor manufacturer |
ARM |
| Processor family |
ARM Cortex |
| Processor model |
A73 |
| Processor frequency |
1.6 GHz |
| Processor cores |
4 |
| Internal memory |
16 GB |
| Operating system installed |
Tizen |
| Operating system version |
Tizen 7.0 |
