| Weight & dimensions |
| Display width |
1681.1 mm |
| Display depth |
49.7 mm |
| Display height |
960.1 mm |
| Display weight |
38.3 kg |
| Display |
| Display diagonal |
190.5 cm (75") |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
No |
| Panel type |
VA |
| Response time |
8 ms |
| Contrast ratio (typical) |
4000:1 |
| Dynamic contrast ratio marketing name |
Mega Contrast |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.42975 x 0.42975 mm |
| Horizontal scan range |
30 - 81 kHz |
| Vertical scan range |
48 - 75 Hz |
| Haze rate |
44% |
| Pixel frequency (max) |
594 MHz |
| RGB colour space |
DCI-P3 |
| Colour gamut |
92% |
| Packaging data |
| Package width |
1871 mm |
| Package depth |
223 mm |
| Package height |
1127 mm |
| Package weight |
49 kg |
| Power |
| Power consumption (typical) |
231 W |
| Power consumption (sleep) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| DVI port |
No |
| DisplayPorts quantity |
1 |
| USB port |
Yes |
| HDMI version |
2.0 |
| HDMI input ports quantity |
3 |
| DisplayPorts in |
1 |
| DisplayPort version |
1.2 |
| USB ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Infrared data port |
Yes |
| Remote (IR) input |
1 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Other features |
| Bluetooth |
Yes |
| Flash memory |
16000 MB |
| RS-232 input ports |
1 |
| RS-232 output ports |
1 |
| RJ-45 input ports |
1 |
| Optional features |
WMN6575SF,WMN4277SF |
| Design |
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Yes |
| Screen shape |
Flat |
| Panel mounting interface |
400 x 400 mm |
| Bezel width (bottom) |
1.25 cm |
| Bezel width (side) |
1.15 cm |
| Bezel width (top) |
1.15 cm |
| Bezel colour |
Charcoal Black |
| Mounting type |
Wall |
| Performance |
| Purpose |
Universal |
| Operating hours (hours/days) |
24/7 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Technical details |
| Audio out (mini jack) |
1 |
| Computer system |
| Computer system |
Yes |
| Built-in processor |
Yes |
| Computer system type |
System on Chip (SoC) |
| Operating system installed |
Tizen 6.5 |
| Certificates |
| Certification |
Class B
60950-1, 62368-1 |
| Logistics data |
| Harmonized System (HS) code |
85285210 |
| Network |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
