| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| HDMI ports quantity |
2 |
| Headphone outputs |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| USB Power Delivery (USB PD) |
Yes |
| HDMI version |
2.1 |
| DisplayPorts quantity |
2 |
| DisplayPort version |
1.4 |
| Combo headphone/mic port |
Yes |
| Headphone connectivity |
3.5 mm |
| DC-in jack |
Yes |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Power |
| Power source type |
DC |
| AC input voltage |
100 - 240 V |
| Input current |
2.5 A |
| Output voltage |
20 V |
| Output current |
10.5 A |
| Power consumption (max) |
210 W |
| Power plug type |
Type M |
| Compatible power plug types |
EU, UK |
| Packaging content |
| Cables included |
AC, USB Type-C |
| AC adapter included |
Yes |
| User guide |
Yes |
| Other features |
| Chipset |
DisplayLink - DL6950, Genesys Logic - GL5911, Genesys Logic - GL5910, Genesys Logic - GL3590, Realtek - RTL8156B |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Wake-on-LAN ready |
Yes |
| Full duplex |
Yes |
| Performance |
| Product colour |
Grey |
| Card reader integrated |
No |
| Data transfer rate |
10 Gbit/s |
| HD type |
4K Ultra HD |
| Maximum digital resolution |
3840 x 2160 pixels |
| Number of displays supported |
3 |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington, Nano, Wedge |
| On/off switch |
Yes |
| UASP support |
Yes |
| Technical details |
| Compliance certificates |
Federal Communications Commission (FCC), RoHS, Trade Agreements Act (TAA) |
| Software |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Mac operating systems supported |
Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma, Mac OS X 15.0 Sequoia |
| Linux operating systems supported |
Ubuntu 18.04 LTS, Ubuntu 20.04 LTS, Ubuntu 22.04, Ubuntu 24.04 LTS |
| Other operating systems supported |
ChromeOS |
| Packaging data |
| Package width |
169 mm |
| Package depth |
251 mm |
| Package height |
90 mm |
| Package weight |
1.2 kg |
| Logistics data |
| Products per master (outer) case |
6 pc(s) |
| Master (outer) case width |
315 mm |
| Master (outer) case length |
395 mm |
| Master (outer) case height |
300 mm |
