| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 2000, Windows 2000 Professional, Windows 7, Win |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Ma |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Other operating systems supported |
Windows XP Embedded |
| Operational conditions |
| Operating temperature (T-T) |
0 - 55 °C |
| Storage temperature (T-T) |
-20 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Power |
| Power source type |
USB |
| Power plug type |
Type M |
| Weight & dimensions |
| Width |
59 mm |
| Depth |
1788 mm |
| Height |
23 mm |
| Weight |
300 g |
| Ports & interfaces |
| Ports quantity |
4 |
| Host interface |
USB 2.0 Type-B |
| Hub interfaces |
Serial |
| RS-232 ports |
4 |
| Other features |
| Chipset |
FTDI - FT4232HL |
| Packaging content |
| Cables included |
USB |
| Manual |
Yes |
| DIN rail kit included |
Yes |
| Drivers included |
Yes |
| Performance |
| Data bits |
7, 8 |
| Stop bits |
1, 2 |
| Parity bit |
Even, Mark, No, Odd, Space |
| FIFO (First In, First Out) |
256 B |
| Baud rate |
921.6 Kbit/s |
| Mean time between failures (MTBF) |
282713.5 h |
| Technical details |
| Compliance certificates |
CE, RoHS |
| Logistics data |
| Master (outer) case width |
432 mm |
| Master (outer) case length |
518 mm |
| Master (outer) case height |
264 mm |
| Products per master (outer) case |
25 pc(s) |
| Harmonized System (HS) code |
84719000 |
| Packaging data |
| Quantity per pack |
1 pc(s) |
| Package width |
216 mm |
| Package depth |
152 mm |
| Package height |
50 mm |
| Package weight |
518 g |
| Features |
| Product colour |
Black |
| Housing material |
Steel |
| LED indicators |
Activity |
| Sustainability |
| Sustainability compliance |
Yes |
