| Weight & dimensions |
| Width |
58.6 mm |
| Depth |
196 mm |
| Height |
24 mm |
| Weight |
340 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
Thunderbolt 3 |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| HDMI ports quantity |
1 |
| Microphone in |
No |
| Headphone outputs |
0 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
85 W |
| VGA (D-Sub) ports quantity |
1 |
| DisplayPorts quantity |
2 |
| DC-in jack |
Yes |
| Power |
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| Input current |
1.8 A |
| Output voltage |
19 V |
| Output current |
6.32 A |
| Power consumption (typical) |
120 W |
| Power plug type |
Type N |
| Compatible power plug types |
EU, UK |
| Packaging content |
| Cables included |
AC, Thunderbolt |
| AC adapter included |
Yes |
| Manual |
Yes |
| Other features |
| Cable length |
0.5 m |
| Chipset |
Intel - Alpine Ridge JHL6540, Intel - WGI210AT, ASMedia - ASM1042A, Parade - PS176, Chrontel - CH7517 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Auto MDI/MDI-X |
Yes |
| Full duplex |
Yes |
| Performance |
| Product colour |
Grey |
| Card reader integrated |
No |
| HD type |
4K Ultra HD |
| Maximum digital resolution |
4096 x 2160 pixels |
| UASP support |
Yes |
| Housing material |
Aluminium |
| Certification |
CE, FCC, REACH |
| Technical details |
| Compliance certificates |
RoHS |
| Software |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Window |
| Mac operating systems supported |
Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Packaging data |
| Package width |
187 mm |
| Package depth |
254 mm |
| Package height |
65 mm |
| Package weight |
1.3 kg |
| Logistics data |
| Products per master (outer) case |
20 pc(s) |
| Master (outer) case width |
390 mm |
| Master (outer) case length |
676 mm |
| Master (outer) case height |
280 mm |
| Harmonized System (HS) code |
84733020 |
