| Weight & dimensions |
| Width |
87 mm |
| Depth |
226 mm |
| Height |
28 mm |
| Weight |
301 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
6 |
| HDMI ports quantity |
2 |
| Microphone in |
Yes |
| Headphone outputs |
1 |
| DisplayPorts quantity |
2 |
| Combo headphone/mic port |
No |
| Headphone connectivity |
3.5 mm |
| DC-in jack |
Yes |
| Power |
| Power source type |
AC |
| AC input voltage |
100 - 240 V |
| Input current |
1 A |
| Output voltage |
20 V |
| Output current |
2 A |
| Power consumption (typical) |
40 W |
| Power plug type |
Type N |
| Compatible power plug types |
AU, EU, JP, UK, US |
| Packaging content |
| Cables included |
USB Type-A to USB Type-C, USB Type-C |
| AC adapter included |
Yes |
| Quick start guide |
Yes |
| Other features |
| Cable length |
0.152 m |
| Chipset |
DisplayLink - DL-6950, VIA/VLI - VL813 |
| Number of microphone inputs |
1 |
| USB data transfer rates |
12,480,5000 Mbit/s |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Auto MDI/MDI-X |
Yes |
| Full duplex |
Yes |
| 10G support |
No |
| Performance |
| Product colour |
Black, Silver |
| Card reader integrated |
No |
| Data transfer rate |
5 Gbit/s |
| Maximum digital resolution |
4096 x 2160 pixels |
| Number of displays supported |
2 |
| On/off switch |
Yes |
| LED indicators |
Power |
| UASP support |
Yes |
| Housing material |
Aluminium, Plastic |
| Brand compatibility |
Any brand |
| Certification |
CE, FCC, REACH |
| Technical details |
| Compliance certificates |
RoHS |
| Software |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Ho |
| Mac compatibility |
Yes |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 13.0 Ventura |
| Packaging data |
| Package width |
130 mm |
| Package depth |
318 mm |
| Package height |
52 mm |
| Package weight |
900 g |
| Logistics data |
| Products per master (outer) case |
10 pc(s) |
| Master (outer) case width |
325 mm |
| Master (outer) case length |
325 mm |
| Master (outer) case height |
305 mm |
| Harmonized System (HS) code |
84733020 |
