| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur |
| Other operating systems supported |
Chrome |
| Operational conditions |
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Ports & interfaces |
| Ports quantity |
4 |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Hub interfaces |
HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.0b |
| Other features |
| Mac compatibility |
Y |
| Performance |
| Harmonized System (HS) code |
84719000 |
| Logistics data |
| Master (outer) case width |
340 mm |
| Master (outer) case length |
535 mm |
| Master (outer) case height |
315 mm |
| Products per master (outer) case |
30 pc(s) |
| Networking |
| Ethernet LAN data rates |
10,100,1000,2000 Mbit/s |
| Networking standards |
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Full duplex |
Y |
| Auto MDI/MDI-X |
Y |
| UASP support |
Y |
| Packaging data |
| Package width |
174 mm |
| Package depth |
142 mm |
| Package height |
32 mm |
| Package weight |
126 g |
| Features |
| Data transfer rate |
5000 Mbit/s |
| Maximum resolution (HDMI) |
3840 x 2160 pixels |
| Product colour |
Black, Grey |
| Housing material |
Plastic |
| USB Power Delivery |
Y |
| USB Power Delivery revision |
3.0 |
| USB Power Delivery up to |
100 W |
| HD type |
4K Ultra HD |
| Number of displays supported |
1 |
| Cable length |
0.3 m |
| Sustainability |
| Sustainability certificates |
CE, RoHS |
