| Weight & dimensions |
| Width |
55 mm |
| Depth |
90 mm |
| Height |
20 mm |
| Weight |
62 g |
| Package width |
145 mm |
| Package depth |
212 mm |
| Package height |
40 mm |
| Package weight |
196 g |
| Performance |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| DVI output |
N |
| HDMI output |
Y |
| DisplayPort output |
N |
| Number of displays supported |
1 |
| USB connector type |
USB Type-A |
| USB connector gender |
Male |
| Internal memory |
512 MB |
| Internal memory type |
DDR2 |
| Maximum resolution |
1920 x 1200 pixels |
| Supported graphics resolutions |
1280 x 960,1600 x 900,1024 x 768 (XGA),1152 x 864 (XGA+),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 768 (WXGA),1280 x 800 (WXGA),1400 x 1050 (SXGA+),1440 x 900 (WXGA+),1600 x 1200 (UXGA),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),80 |
| Supported video modes |
1080p,720p |
| Output colour depth |
16/32 bit |
| Audio output channels |
5.1 channels |
| Chipset |
DisplayLink - DL-3500 |
| USB pass-through |
N |
| RoHS compliance |
Y |
| Certification |
CE, FCC, DisplayLink |
| USB connector form factor |
Straight |
| Packaging content |
| Manual |
Y |
| Software CD |
Y |
| System requirements |
| Windows operating systems supported |
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Wind |
| Mac compatibility |
Y |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.15.3 Catalina,Mac OS X 10.6 Snow Leopard,Mac OS X 10.7 Lion,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks,Mac OS X 11.0 |
| Linux operating systems supported |
Ubuntu 14.04,Ubuntu 16.04,Ubuntu 18.04 LTS |
| Other operating systems supported |
Chrome |
| Minimum processor family |
Core i5 |
| Minimum processor speed |
2.4 GHz |
| Minimum RAM |
4 GB |
| Design |
| Product colour |
Black |
| Housing material |
Plastic |
| Integrated USB cable |
Y |
| USB cable length |
0.9 m |
| Technical details |
| Sustainability certificates |
RoHS |
| Operational conditions |
| Operating temperature (T-T) |
0 - 35 °C |
| Storage temperature (T-T) |
20 - 80 °C |
| Operating relative humidity (H-H) |
-5 - 40% |
| Logistics data |
| Products per master (outer) case |
40 pc(s) |
| Master (outer) case width |
42.7 cm |
| Master (outer) case length |
44.2 cm |
| Master (outer) case height |
32.9 cm |
