| Weight & dimensions |
| Width |
51 mm |
| Depth |
96 mm |
| Height |
18 mm |
| Weight |
64 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity |
2 |
| HDMI ports quantity |
1 |
| Microphone in |
N |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB connector type |
USB Type-C |
| DC-in jack |
Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB Power Delivery |
Y |
| USB Power Delivery up to |
60 W |
| Power |
| Power source type |
DC, USB |
| Packaging content |
| Quick start guide |
Y |
| Other features |
| Cable length |
0.348 m |
| Chipset |
VIA/VLI - VL813, VIA/VLI - VL100, Chrontel - CH7525A, ASIX - AX88179 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-10 - 65 °C |
| Operating relative humidity (H-H) |
0 - 85% |
| Networking |
| Ethernet LAN |
Y |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wake-on-LAN ready |
Y |
| Networking standards |
IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Auto MDI/MDI-X |
Y |
| Performance |
| Product colour |
Black |
| Card reader integrated |
N |
| Data transfer rate |
5 Gbit/s |
| Maximum digital resolution |
4096 x 2160 pixels |
| UASP support |
Y |
| Housing material |
Plastic |
| RoHS compliance |
Y |
| Certification |
CE, FCC, TAA, REACH |
| Technical details |
| Sustainability certificates |
RoHS |
| Software |
| Windows operating systems supported |
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Win |
| Mac compatibility |
Y |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks |
| Other operating systems supported |
Chrome |
| Packaging data |
| Package width |
146 mm |
| Package depth |
212 mm |
| Package height |
41 mm |
| Package weight |
198 g |
| Logistics data |
| Quantity per master (outer) case |
40 pc(s) |
| Master (outer) case width |
31.7 cm |
| Master (outer) case length |
42 cm |
| Master (outer) case height |
43.5 cm |
| Products per master (outer) case |
40 pc(s) |
| Sustainability |
| Sustainability certificates |
RoHS |
