| Networking |
| Maximum data transfer rate |
5000 Mbit/s |
| Networking standards |
IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN |
Yes |
| Ethernet interface type |
2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Cabling technology |
NBase-T |
| Wake-on-LAN ready |
Yes |
| Auto MDIX IEEE |
Yes |
| Full duplex |
Yes |
| Jumbo frames support |
Yes |
| Auto-negotiation |
Yes |
| Jumbo frames |
16000 |
| VLAN tagging |
Yes |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Server 2022 |
| Weight & dimensions |
| Depth |
22 mm |
| Height |
15 mm |
| Weight |
24.7 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB Type-C |
| Interface |
Ethernet |
| Ethernet LAN (RJ-45) ports |
1 |
| USB connector form factor |
Straight |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| USB pass-through |
No |
| Operational conditions |
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-10 - 70 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Power |
| Output voltage |
5 V |
| USB powered |
Yes |
| Other features |
| Cable length |
0.15 m |
| Design |
| Internal |
No |
| Component for |
PC/Server |
| Product colour |
Grey |
| Chipset |
Realtek RTL8156BG |
| LED indicators |
Yes |
| Mean time between failures (MTBF) |
1912948 h |
| Logistics data |
| Master (outer) case width |
500 mm |
| Master (outer) case length |
320 mm |
| Master (outer) case height |
210 mm |
| Products per master (outer) case |
250 pc(s) |
| Packaging data |
| Package width |
220 mm |
| Package depth |
128 mm |
| Package height |
16 mm |
| Package weight |
27 g |
| Technical details |
| Compliance certificates |
CE, Federal Communications Commission (FCC) |
