| Networking |
| Maximum data transfer rate |
5000 Mbit/s |
| Networking standards |
IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000BaseT(X) |
| Wake-on-LAN ready |
Yes |
| Auto MDIX IEEE |
Yes |
| Full duplex |
Yes |
| Jumbo frames support |
Yes |
| Jumbo frames |
9000 |
| VLAN tagging |
Yes |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Window |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac |
| Linux operating systems supported |
Yes |
| Other operating systems supported |
ChromeOS |
| Server operating systems supported |
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019 |
| Weight & dimensions |
| Width |
37 mm |
| Depth |
255 mm |
| Height |
17 mm |
| Weight |
25.9 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB |
| Interface |
Ethernet |
| Ethernet LAN (RJ-45) ports |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity |
2 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-10 - 55 °C |
| Operating relative humidity (H-H) |
40 - 50% |
| Power |
| Power consumption |
1092 mA |
| USB powered |
Yes |
| Other features |
| Housing material |
Plastic |
| Flow control support |
Yes |
| Design |
| Internal |
No |
| Product colour |
Black |
| Chipset |
Realtek RTL8153 |
| Mean time between failures (MTBF) |
637901 h |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Master (outer) case width |
355 mm |
| Master (outer) case length |
455 mm |
| Master (outer) case height |
270 mm |
| Products per master (outer) case |
200 pc(s) |
| Packaging data |
| Package width |
128 mm |
| Package depth |
220 mm |
| Package height |
30 mm |
| Package weight |
106 g |
| Technical details |
| Compliance certificates |
CE, RoHS |
| Packaging content |
| Manual |
Yes |
