| System requirements |
| Windows operating systems supported |
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 2000,Windows 2000 Professional,Windows 7,Windows 7 Enterp |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported |
Y |
| Other operating systems supported |
Windows XP Embedded |
| Compatible operating systems |
Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016 |
| Server operating systems supported |
Windows Server 2003,Windows Server 2008 R2,Windows Server 2012,Windows Server 2012 R2,Windows Server 2016,Windows Server 2019 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 55 °C |
| Storage temperature (T-T) |
-20 - 85 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Power |
| Power source type |
USB |
| Plug type |
Type M |
| Power plug type |
Type M |
| Weight & dimensions |
| Width |
59 mm |
| Depth |
1788 mm |
| Height |
23 mm |
| Weight |
300 g |
| Ports & interfaces |
| Host interface |
USB 2.0 Type-B |
| Ports quantity |
4 |
| Hub interfaces |
Serial |
| RS-232 ports |
4 |
| Other features |
| Chipset |
FTDI - FT4232HL |
| Packaging content |
| Cables included |
USB |
| Manual |
Y |
| DIN rail kit included |
Y |
| Drivers included |
Y |
| Performance |
| Stop bits |
1,2 |
| Parity bit |
Even, Mark, N, Odd, Space |
| FIFO (First In, First Out) |
256 B |
| Baud rate |
921.6 Kbit/s |
| Mean time between failures (MTBF) |
282713.5 h |
| Data bits |
7,8 |
| Design |
| Product colour |
Black |
| Material |
Steel |
| LED indicators |
Activity |
| Certification |
CE, FCC, RoHS |
| Packaging data |
| Package width |
216 mm |
| Package depth |
152 mm |
| Package height |
50 mm |
| Package weight |
518 g |
| Quantity per pack |
1 pc(s) |
| Features |
| Product colour |
Black |
| Housing material |
Steel |
| LED indicators |
Activity |
| Certification |
CE, FCC, RoHS |
